The Walkie-Talkie Converter-K includes a power interface (DC), a transceiver interface for walkie-talkie connection, a 4-wire audio OUT interface (XLR), a 4-wire audio IN interface (XLR), and a 4-wire audio interface (RJ45).
Power
It is powered by a DC 12V supply and consumes less than 1W when the VOX switch is set to ON.
Audio Performance
The unit offers a VOX threshold greater than –23dBu, a signal-to-noise ratio of more than 55dB, and a frequency range of 100 Hz to 20 kHz. It supports a maximum input level of 18dBu, with a gain of –40dB from the 4-wire interface to the walkie-talkie and +4dB from the walkie-talkie to the 4-wire interface. Distortion levels remain below 1%.
Physical Specifications
The Walkie-Talkie Converter-K measures 144.8mm × 75.5mm × 36.5mm (5.7″ × 2.97″ × 1.4″) and has a net weight of approximately 349.5g (12.3oz).
Environmental Conditions
It operates reliably in temperatures ranging from 0℃ to 45℃ (32℉ to 113℉).
Compatibility
The device is designed for integration with compatible 4-wire audio systems and walkie-talkie setups.
