The Walkie-Talkie Converter-2C includes a DC power interface, a transceiver interface for walkie-talkie connection, a 4-wire audio OUT interface (XLR), a 4-wire audio IN interface (XLR), and a 4-wire audio interface (RJ45).
Power
It operates on a DC 12V supply and consumes less than 1W with the VOX switch turned on.
Audio Performance
The unit provides a VOX threshold greater than –23dBu, a signal-to-noise ratio exceeding 55dB, and a frequency range of 100 Hz to 20 kHz. It supports a maximum input level of 18dBu, with –40dB gain from the 4-wire interface to the walkie-talkie and +4dB gain from the walkie-talkie to the 4-wire interface. Distortion remains below 1%.
Physical Specifications
The Walkie-Talkie Converter-2C measures 144.8mm × 75.5mm × 36.5mm (5.7″ × 2.97″ × 1.4″) and weighs approximately 349.5g (12.3oz).
Environmental Conditions
It is designed for reliable operation in environments ranging from 0℃ to 45℃ (32℉ to 113℉).
Compatibility
The device is engineered to integrate smoothly with walkie-talkies and 4-wire audio systems.
