DZOFilm Catta Ace 35-80mm T2.9 Cine Zoom Lens (PL/EF Mount)

Code: VGU/DZO-FFA3580-BLK
$3,745.00

With this Catta Ace FF 18-35/35-80/70-135mm T2.9 Cine 3-Lens Bundle from DZOFilm, you can add three full-frame zoom lenses to your production equipment to cover various focal lengths and cameras.

Add to Cart

This item is already in your cart, click here to update quantities.

ENQUIRE NOW

Got a question about this product?
Send us a message

Special Order Item

Usually ships in 1-2 weeks

Request ETA

What's In The Box?

  • Catta Ace 35-80mm T2.9 Cine Zoom Lens
  • Front Cap
  • PL Rear Cap
  • EF Bayonet
  • EF Rear Cap
  • Shim Set
  • Support Base
  • Support Rod
  • Add a cinema zoom lens to your documentary, broadcast, or online production kit with this Catta Ace 70-135mm T2.9 PL-Mount Cine Zoom Lens from DZOFilm. The cine zoom lens is designed to maintain focus as you smoothly zoom in or out. The Catta line reproduces accurate colour and features a smooth focus/defocus transition. It features a wide T2.9 to T22 aperture, a 16-blade iris for smooth bokeh, and a long 75cm close focus range.

    Key Features

    • Maintains Focus Throughout Zoom Range
    • Natural Colour Rendering
    • Consistent T2.9 to T22 Aperture
    • Covers Full-Frame Sensors
    • 16-Blade Iris for Soft Bokeh
    • 75cm Minimum Focus Distance
    • PL Mount Installed, EF Mount Included
    • 240-Degree Focus Rotation
    • M77 Filter Diameter
    • 80mm Front Diameter

    True to its cine design, it has a focus rotation of 240°, a 100° zoom rotation range, and an 80° iris rotation range. The lens features a PL mount, and an EF mount is included to change out using a screw and shim set. Multiple accessories are included with the lens, including front and rear lens caps, a support base, a support rod, and a filter bracket.


    Specifications
    Focal Length 35 – 80 mm
    Lens Mount PL
    Format Full frame
    Image Circle 43.5 mm
    Maximum Aperture T2.9
    Minimum Aperture T22
    Minimum Focus Distance 75cm
    Optical Design 20 elements, 15 groups
    Diaphragm Blades 16
    Gear MOD & Pitch Focus: 0.8 MOD / 32 Pitch

    Iris: 0.8 MOD / 32 Pitch

    Zoom: 0.8 MOD / 32 Pitch

    Front Diameter 80mm
    Filter Thread 77mm
    Focus Rotation 240°
    Iris Rotation 75°
    Zoom Rotation 100°
    Zoom Ratio 2.3x
    Image Stabilisation No
    Weight 1532 g
