Miller Sprinter II 2 Stage Carbon Fibre Legs

Item Code: MIL/1576

Miller

The Miller Sprinter II 2-stage, carbon fibre, mid level spreader tripod (1576) employs the patented Miller design that enables the leg stages to be adjusted independently via two leg locks conveniently located high above the ground thus eliminating the need for the operator to bend down.
Out of stock - Usually ships in 3-5 days

EOFY Sale - Save an extra 15%!

We've taken an extra 15% off our already discounted prices on Miller products ordered before 5pm 21/06/19 *

Excludes Skyline 90 and spare parts. Not available in conjunction with other specials or offers.

1513.6364

  • Qty:
  • Price:
    $1,415.25
    inc. GST

The Miller Sprinter II 2-stage, carbon fibre, mid level spreader tripod (1576) employs the patented Miller design that enables the leg stages to be adjusted independently via two leg locks conveniently located high above the ground thus eliminating the need for the operator to bend down.

The Sprinter II dual action leg lock system is designed for operators who require speed and convenience of setup without compromise. By placing independent leg lock levers adjacent to each other, both the upper and lower stages they can be operated in unison or independently from one single upper leg location.

The unique intertwined layered construction method of the carbon/basalt fibre gives the tripod tubes incredible stiffness to the leg assembly.

The leg assemblies are integrated with the 100mm die-cast alloy bowl with precision resulting in a highly rigid tripod no matter what height you choose.

Features

  • 100mm alloy bowl.
  • High speed independent 2-stage dual leg locks.
  • Lightweight carbon fibre tubing.
  • In-line carry handle.
  • Suited for mid-level spreader.
  • Integrated stainless steel spikes.
  • Stay flat rubber feet (optional).
  • Integrated transport clips.
  • 3 year warranty.

Specifications

Maximum Payload Capacity 45kg (100lbs)
Weight 3.2kg (7.0lbs)
Height Range 440-1530mm (17.3-60.4")
Transport Length 700mm (27.6”)
Mounting Base Ø100mm (3.9") ball levelling
Leg Extension 2-stage
Lock Type HS Dual Action
Leg Material Carbon fibre
