| Camera |
|---|
| Image Sensor | Type 1/2.3 (1/2.3 in.) single-plate CMOS sensor |
| Effective Pixels | approx. 8.29 megapixels (3840 x 2160) |
| Lens | f=3.67 – 73.4 mm, F/1.8 – 2.8, 20x optical zoom, 8-bladed circular aperture |
| Optical Zoom | 20x optical zoom |
| Digital Zoom | 20x digital zoom |
| Focal Length | f=3.67 – 73.4 mm, F/1.8 – 2.8,
35mm equivalent focal length:
[4K UHD] approx. 29.3 (W) – 601 mm (T)
[Full HD] approx. 30.5 (W) – 627 mm (T)
Digital |
| Angle of View | [4K UHD]
Horizontal: 65.6 (W) – 3.6° (T)
Vertical: 39.8° (W) – 2.0° (T)
[Full HD]
Horizontal: 63.5 (W) – 3.4° (T)
Vertical: 38.4° (W) – 1.9° (T) |
| Minimum Subject Illumination | Approx. 1.5 lux (shutter speed 1/30 sec., frame rate 59.947P (Programmed AE) shooting mode, auto slow shutter on) |
| Shutter Speed | 1/6 – 1/2000 sec. (specific values depend on the frame frequency and frame rate) |
| Iris | Manual/Automatic aperture |
| Gain | 0.0 dB – 36 dB |
| ND Filter | Built-in (1/8 at maximum, gradation ND), motor operate |
| White Balance | AUTO (AWB), Set A, Set B, preset settings (daylight: 5,600 K*, tungsten lamp: 3,200 K*), color temperature setting (2,000 K – 15,000 K), Manual
* Color temperatures are given for reference purposes only. |
| Focus | Focus mode: Manual, Continuous AF, Face AF, Tracking
AF type: Hybrid AF, Contrast AF |
| Gamma | Normal1 (Standard), Normal3 (BT.709) |
| Pan and Tilt | Pan operation range: Horizontal ±170°
Pan operation speed: 0.2° – 300°/sec.
Tilt operation range: Vertical -30° – +100°
Tilt operation speed: 0.2° – 180°/sec. |
| Pan and Tilt Operation |
|---|
| Protocol | XC (Canon's original), RTSP/RTP, NDI|HX, RTMP/RTMPS, Standard Communication (Serial), Standard Communication (IP), SRT, FreeD |
| Server |
|---|
| Video Output Format: SDI | 1920 x 1080: 59.94P/59.94i, 50.00P/50.00i/25.00P, 29.97P/23.98P (4:2:2 10 bit)
1280 x 720: 59.94P, 50.00P (4:2:2 10 bit)
– Same video format required for SDI and HDMI (cannot select different formats for SDI and HDMI)
– When 3840 x 2160 is selected for HDMI, video will not be outputted to SDI. |
| Video Output Format: HDMI | HDMI 3840 x 2160: 29.97P, 25.00P, 23.98P (4:2:2 10 bit)
1920 x 1080: 59.94P/59.94i, 50.00P/50.00i/25.00P, 29.97P/23.98P (4:2:2 10 bit)
1280 x 720: 59.94P, 50.00P (4:2:2 10 bit)
– Same video format required for SDI and HDMI (cannot select different formats for SDI and HDMI)
– When 3840 x 2160 is selected for HDMI, video will not be outputted to SDI. |
| Video Output Format: IP | 3840 x 2160: 29.97 fps, 14.99 fps, 5.00 fps (4:2:0 8 bit)
1920 x 1080: 59.94 fps, 29.97 fps, 14.99 fps, 5.00 fps (4:2:0 8 bit)
1280 x 720: 59.94 fps, 29.97 fps, 14.99 fps, 5.00 fps (4:2:0 8 bit)
640 x 360: 59.94 fps, 29.97 fps, 14.99 fps, 5.00 fps (4:2:0 8 bit)
– If 59.94/50.00 Hz is selected for the frame frequency, the 3840 x 2160 format cannot be selected.
– A frame rate that exceeds the frame frequency cannot be selected.
– JPEG has one pattern fixed depending on the frame frequency (format is fixed and cannot be selected)
Resolution: 1280 x 720
When frame frequency is 59.94/50.00 Hz: 14.99 fps, when frame frequency is 23.98 Hz: 11.99 fps, when frame frequency is 29.97/25.00 Hz: 12.50 fps |
| Video Output Format: USB | Motion JPEG:
1920 x 1080
59.94 Hz: 30.00 fps, 15.00 fps, 5.00 fps
50.00 Hz: 25.00 fps, 12.50 fps, 5.00 fps
1280 x 720
59.94 Hz: 30.00 fps, 15.00 fps, 5.00 fps
50.00 Hz: 25.00 fps, 12.50 fps, 5.00 fps
640 x 360
59.94 Hz: 30.00 fps, 15.00 fps, 5.00 fps
50.00 Hz: 25.00 fps, 12.50 fps, 5.00 fps
YUV:
640 x 360
59.94 Hz: 30.00 fps, 15.00 fps, 5.00 fps
50.00 Hz: 25.00 fps, 12.50 fps, 5.00 fps |
| Preset | Number of presets: Max. 100 (including home position) |
| Interface |
|---|
| Communication Control | LAN, Wi-Fi, Serial, IR |
| Network Terminal | LAN x 1, RJ45, 1000Base-T |
| SDI OUT Terminal | BNC jack (output only) x 1, 0.8 Vp-p/75 Ω, unbalanced
SMPTE 424, SMPTE 425, SMPTE ST 299-2 compliant
Embedded audio, Time code (VITC/LTC) |
| GEN-LOCK Terminal | - |
| HDMI OUT Terminal | HDMI connector x 1, output only |
| RS-422 Terminal | RJ45 connector x 1 |
| INPUT 1/INPUT 2 Terminals | - |
| MIC Terminal | Ď•3.5 mm stereo mini jack (unbalanced, plug-in power supported)
Sensitivity (MIC): -72 dBV (Manual volume center, full scale -18 dB)/1 kΩ or
more/Att.: 20 dB
Sensitivity (LINE): -10 dBV (Manual volume center, full scale -18 dB)/1 kΩ or more
Supply Voltage: 2.4 V DC (Bias resistance: 2.2 kΩ) |
| USB Terminal | Type-A (USB 2.0) x 1 (future expansion)
Type-C (USB 3.0) x 1 |
| Physical Features |
|---|
| Operating Environment | Temperature
0°C – +40°C (+32°F – +104°F)
Humidity
10% – 90% (without condensation) |
| Power Supply | PoE: PoE+ power supply via LAN connector (IEEE802.3at compliant)
– PoE cannot be used
External power source: 24 V DC (using included AC adaptor) |
| Power Consumption | PoE+ Input: Approx. 16.2 W* max. (body only)
DC Input: Approx. 15.0 W max. (body only)
* Class 4 (25.5 W required) for power supply devices |
| Dimensions (W x H x D) | Approx. 154 x 178 x 164 mm (6.06 x 7.01 x 6.46 in.) (excluding protrusions) |
| Weight | Approx. 2.2 kg (4.86 lb.) (body only) |
| IP Rating | - |
