| SENSOR TYPE |
MONSTRO 35.4 Megapixel CMOS |
HELIUM 35.4 Megapixel CMOS* |
RED DRAGON 19.4 Megapixel CMOS |
| EFFECTIVE PIXELS |
8192 × 4320 |
8192 × 4320 |
6144 × 3160 |
| SENSOR SIZE |
40.96 mm x 21.60 mm (Diagonal: 46.31 mm) |
29.90 mm x 15.77 mm (Diagonal: 33.80 mm) |
30.7 mm x 15.8 mm (Diagonal: 34.5 mm) |
| DYNAMIC RANGE |
17+ stops |
16.5+ stops |
16.5+ stops |
| MAX FRAME RATES1 |
60 fps at 8K Full Format (8192 × 4320), 75 fps at 8K 2.4:1 (8192 × 3456)
60 fps at 7K Full Format (7168 × 3780), 75 fps at 7K 2.4:1 (7168 × 3024)
75 fps at 6K Full Format (6144 × 3240), 100 fps at 6K 2.4:1 (6144 × 2592)
96 fps at 5K Full Format (5120 × 2700), 120 fps at 5K 2.4:1 (5120 × 2160)
120 fps at 4K Full Format (4096 × 2160), 150 fps at 4K 2.4:1 (4096 × 1728)
150 fps at 3K Full Format (3072 × 1620), 200 fps at 3K 2.4:1 (3072 × 1296)
240 fps at 2K Full Format (2048 × 1080), 300 fps at 2K 2.4:1 (2048 × 864) |
75 fps at 6K Full Format (6144 × 3160), 100 fps at 6K 2.4:1 (6144 × 2592)
96 fps at 5K Full Format (5120 × 2700), 120 fps at 5K 2.4:1 (5120 × 2160)
120 fps at 4K Full Format (4096 × 2160), 150 fps at 4K 2.4:1 (4096 × 1728)
150 fps at 3K Full Format (3072 × 1620), 200 fps at 3K 2.4:1 (3072 × 1296)
240 fps at 2K Full Format (2048 × 1080), 300 fps at 2K 2.4:1 (2048 × 864) |
| MAX DATA RATES |
Up to 300 MB/s using RED MINI-MAG (480GB & 960GB)
Up to 225 MB/s using RED MINI-MAG (120GB & 240GB) |
PLAYBACK FRAME RATES
(PROJECT TIMEBASE) |
23.98, 24, 25, 29.97, 47.95, 48, 50, 59.94, 60 fps, all resolutions |
REDCODE SETTINGS
RANGE FROM 2:1 UP TO 22:11 |
5:1 REDCODE for 8K Full Format (8192 × 4320) at 24 fps
12:1 REDCODE for 8K Full Format (8192 × 4320) at 60 fps
2:1 REDCODE for 4K Full Format (4096 × 2160) at 24 fps
3:1 REDCODE for 4K Full Format (4096 × 2160) at 60 fps |
3:1 REDCODE for 6K Full Format (6144 × 3160) at 24 fps
7:1 REDCODE for 6K Full Format (6144 × 3160) at 60 fps
2:1 REDCODE for 4K Full Format (4096 × 2160) at 24 fps
3:1 REDCODE for 4K Full Format (4096 × 2160) at 60 fps |
REDCODE RAW
ACQUISITION FORMATS2 |
8K Full Format (8192 × 4320), 2:1, 2.4:1, 16:9, 14:9, 8:9, 3:2, 6:5, 4:1, 8:1, and Ana 2x, 1.3x, 1.25x
7K Full Format (7168 × 3780), 2:1, 2.4:1, 16:9, 8:9, 6:5, 4:1, 8:1, and Ana 2x, 1.3x
6K Full Format (6144 × 3240), 2:1, 2.4:1, 16:9, 8:9, 3:2, 4:3, 6:5, 4:1, 8:1, and Ana 2x, 1.3x, 1.25x
5K Full Format (5120 × 2700), 2:1, 2.4:1, 16:9, 8:9, 6:5, 4:1, 8:1, and Ana 2x, 1.3x
4K Full Format (4096 × 2160), 2:1, 2.4:1, 16:9, 8:9, 3:2, 4:3, 5:4, 6:5, 4:1, 8:1, 1:1, and Ana 2x, 1.3x
3K Full Format (3072 × 1620), 2:1, 2.4:1, 16:9, 3:2, 4:3, 5:4, 6:5, 4:1, 8:1, and Ana 2x, 1.3x
2K Full Format (2048 × 1080), 2:1, 2.4:1, 16:9, 3:2, 4:3, 5:4, 6:5, 4:1, 8:1, and Ana 2x, 1.3x |
6K Full Format (6144 × 3160), 2:1, 2.4:1, 16:9, 3:2, 6:5, 4:1, 8:1, and Ana 2x, 1.3x, 1.25x
5K Full Format (5120 × 2700), 2:1, 2.4:1, 16:9, 6:5, 4:1, 8:1, and Ana 2x, 1.3x
4K Full Format (4096 × 2160), 2:1, 2.4:1, 16:9, 3:2, 4:3, 5:4, 6:5, 4:1, 8:1, and Ana 2x, 1.3x
3K Full Format (3072 × 1620), 2:1, 2.4:1, 16:9, 3:2, 4:3, 5:4, 6:5, 4:1, 8:1, and Ana 2x, 1.3x
2K Full Format (2048 × 1080), 2:1, 2.4:1, 16:9, 3:2, 4:3, 5:4, 6:5, 4:1, 8:1, and Ana 2x, 1.3x |
| APPLE PRORES |
ProRes 422 HQ, ProRes 422 and ProRes 422 LT at 4K (4096 × 2160) up to 29.97 fps
ProRes 4444 XQ and ProRes 4444 at 2K (2048 × 1080) up to 120 fps
ProRes 422 HQ, ProRes 422 and ProRes 422 LT at 2K (2048 × 1080) up to 120 fps |
| AVID CODECS3 |
DNxHR HQX at 4K (4096 × 2160) 12-bit up to 29.97 fps
DNxHR HQ, SQ and LB at 4K (4096 × 2160) 8-bit up to 29.97 fps
DNxHR 444 at 2K (2048 × 1080) 12-bit up to 120 fps
DNxHD 444 and HQX (1920 × 1080) 10-bit up to 120 fps
DNxHD HQ, SQ and LB (1920 × 1080) 8-bit up to 120 fps |
| CONSTRUCTION |
Carbon Fiber, Magnesium, and Aluminum Alloy |
| WEIGHT |
3.3 lbs (BRAIN with Integrated Media Bay) |
| OPERATING TEMPERATURE |
0°C to 40°C (32°F to 104°F) |
| STORAGE TEMPERATURE |
–20°C to 50°C (–4°F to 122°F) |
| RELATIVE HUMIDITY |
0% to 85% non-condensing |
| COLOR MANAGEMENT |
Supports 33×33×33, 32×32×32, 26×26×26, and 17×17×17 3D LUTs
Variable number of 3D LUT outputs with DSMC2 expander module
User programmable shaper 1D LUTs
Tetrahedral interpolation, 16-bit processing |
| AUDIO |
Integrated dual channel digital stereo microphones, uncompressed, 24-bit 48 kHz
Optional 2 additional channels with DSMC2 expander module, uncompressed, 24-bit 48 kHz |
| REMOTE CONTROL |
Integrated R.C.P. WiFi antenna
Ethernet, RS232, and GPI Trigger with DSMC2 expander module |
| MONITOR OUTPUTS |
3G-SDI (HD-SDI) and HDMI with DSMC2 expander module
1080p RGB or 4:2:2, 720p RGB or 4:2:2
480p RGB or 4:2:2 (HDMI only)
SMPTE Timecode, HANC Metadata, 24-bit 48 kHz Audio |
| MONITOR OPTIONS |
DSMC2 RED Touch 4.7" LCD, DSMC2 RED Touch 7.0" LCD and DSMC2 RED EVF (OLED) with cable-free connection.
RED Touch 9.0" LCD, RED Touch 7.0" LCD, RED Touch 5.0" LCD, RED PRO 7" LCD, BOMB EVF (OLED) and BOMB EVF (LCOS) compatible with DSMC2 LEMO Adaptor A and LCD/EVF cable. |
REDCINE-X PRO
DELIVERY FORMATS |
4K: DPX, TIFF, OpenEXR (.RED via RRencode plugin)
2K: DPX, TIFF, OpenEXR (.RED via RRencode plugin)
1080p RGB 4:2:2, 720p 4:2:2 : QuickTime, JPEG, AVID AAF, MXF
1080p 4:2:0, 720p 4:2:0 : H.264, .MP4 |
VIDEO EDITING SOFTWARE
COMPATIBILITY4 |
Adobe Premiere Pro, AVID Media Composer,
DaVinci Resolve, Edius Pro, Final Cut Pro, Vegas Pro |
