Zacuto Komodo Cage Ki w/ Kameleon PRO EVF

Code: ZAC/Z-RK-K2
The RED Komodo cage from Zacuto features a modular design consisting of top plate, two sides and a bottom, which can each be used individually or in any combination.

For purchasing information

Enquire Now

The RED Komodo cage from Zacuto features a modular design consisting of top plate, two sides and a bottom, which can each be used individually or in any combination.

The top plate has an integrated Z-Rail (NATO rail) for quick mounting rail based top handles, arms, monitor mounts, etc. and a flush top for mounting other accessories. It contains a number of 1/4" 20 and Arri style 3/8" 16 threaded holes on top and sides. There is also a provision for mounting two 15mm rod locks for rods to support focus motors and other top mounted rod accessories

Both side rails are Zacuto independent Z-Rails (NATO) featuring two Arri M6 rosettes top and bottom and an Arri 3/8 16 tapped hole.

The bottom plate has an integrated Arca Swiss style locking wedge, an integrated and adjustable 1/4" 20 screw support for lens adaptors and 1/4" 20 threaded holes on the sides.

The cage is super lightweight and crafted from aircraft aluminium. It protects the corners of the camera body and ergonomical and low profile.

The Tactical handle can be a top handle, left hand grip, or right hand grip with the twist of a lever- use it where you need it for your shooting style. The slim design fits comfortably in your hand.

The Rosette Trigger Handgrip is a very compact low profile trigger grip that rotates 360 degrees with a simple press of a lever- rock solid. It attaches to an Arri M6 Rosette, located on the side plate of the cage.

This kit includes:

RED Komodo Cage Kit - top plate, bottom plate, two sides plus the Tactical Handle and The Rosette Trigger Handgrip.

Axis Micro - simple and efficient EVF Mount to mount the Kameleon EVF to the Tactical Handle

Kameleon Pro EVF - high quality professional EVF offers all the excellent features like Waveform, Vectorscope, Zebras, Peaking, 3D Luts and much more. To view all the specs of the Kameleon, visit here.

4 pin Lemo to D-tap + SDI cable - a combined 4 pin lemo to d-tap cable with an SDI cable.
