Transmit zero-delay, uncompressed, 4Kp60 video and camera control commands over a range of up to 1,000 ft. (305m). The Orbit PTZ mounts beneath any PTZ camera and includes a looping power supply, giving you a seamless, long-range wireless solution for quick deployment and cable-free workflows.
Live Production Has Never Looked This Good
Orbit PTZ takes your PTZ camera and makes it completely wireless. Transmit uncompressed 4K / HD video, as well as Sony VISCA and Panasonic camera control commands up to 1,000 ft. away with no delay.
Power Through Channel Interference
Orbit PTZ uses Teradek's patented Joint Source Channel Coding (JSCC) to transmit video over the unlicensed 5GHz band, providing far better channel utilisation and handling of interference than competing H.264 / HEVC transmission methods.
Real-Time Camera Control
Orbit PTZ features RS-232 and RS-422 connectivity for PTZ camera control. Camera commands travel over a zero-latency wireless link between transmitter and receiver, with support for VISCA and Panasonic AW protocols.
Unbreakable Encryption
Orbit PTZ offers the industry’s best protection against prying eyes with AES-256 encryption and RSA 1024 key pairing. Combined, these two technologies ensure nobody can decrypt your wireless feed or connect another receiver to your system without explicit authorisation.
Easy Mobile Configuration
Command your wireless workflow from the palm of your hand with the Launchpad app for iOS and Android. Pair transmitters and receivers with the touch of a button, monitor channel interference, set operating frequencies, and control your PTZ cameras directly from the app, no cables needed!
Features
- Wireless 4K HDR video with < 1 ms latency
- Uncompressed, 10-bit, 4:2:2 image quality
- Up to 300m of wireless range
- License-free 5GHz operation
- Transmit PTZ camera control commands via RS-232 and RS-422
- AES-256 and RSA 1024 encryption
- Integrated tally light
Uncompressed 4K HDR Video
Less than 1 ms Latency
Integrated Tally Light
Universal Mounting and Power Options
License-Free 5 GHZ Operation
With Manual Channel Selection
Unbreakable Encryption
AES-256 and RSA-1024
Compatibility
PTZ Cameras:
Panasonic: AW-HE38H, AW-HN38H, AW-HE40H, AW-HN40H, AW-HE40S, AW-HE42, AW-UE70, AW-UN70, AW-HE130, AW-HN130, AW-UE150
Sony: BRC-X400, BRC-X1000/1, BRC-X1000/WPW, BRC-H900, BRC-H800/1, BRC-H800/WPW, SRG-360SHE, SRG-300SE, SRG-300H, SRG-300H/W, SRG-120DH, SRG-120DS, SRG-120DU
PTZ Optics: SDI Cameras (6 models), USB3 Cameras (4 models), NDI Cameras (8 models)
Bolin Technology: VCC-8-4K20S-3SM
Ross Video: PIVOTCam-SE, PIVOTCam-20
Newtek: NDI PTZ Camera
Lumens: VC-A70H, VC-A60S, VC-A50PN, VC-A50P, VC-A51S
Marshall Electronics: CV620-WH2 / CV620-BK, CV620-NDI / CV620-NDIW, CV620-IP / CV620-IPW
Controllers:
Sony: RM-IP10, RM-IP500
Panasonic: AW-RP50, AW-RP60, AW-RP150
HuddleCam: HDHC-JOY-G2 PTZ
