Support for Apple ProRes 4444*, 422 (HQ), 422 and DNxHD 220x and 145 at variety of frame rates**
The CBK-55PD codec board provides additional support for Apple ProRes and DNxHD with the PMW-F55 and PMW-F5 CineAlta cameras. This includes ProRes 4444 12-bit Full HD at 23.98P, 24P, 25P and 29.97P. ProRes 422 (HQ), ProRes 422, DNxHD 220x and DNxHD 145 at a variety of frame rates are also supported.
* ProRes 4444 will be supported via firmware update in 1H/2015.
** CBK-55PD must be fitted at a Sony Service Centre. Firmware update V5.0 is also required.
ProRes 4444 support for PMW-F55 and PMW-F5
Supports ProRes 4444 12-bit Full HD at 23.98P, 24P, 25P and 29.97P.
* Requires firmware update in 1H/2015.
ProRes 422 (HQ) and ProRes 422
Supports ProRes 422 (HQ) 10-bit Full HD and ProRes 422 10-bit Full HD at 23.98P, 24P, 25P, 29.97P, 50i, 59.94i, 50P* and 59.94P*.
* Requires firmware update in 1H/2015.
DNxHD 220x and DNxHD 145
Supports DNxHD 220x 10-bit Full HD and DNxHD 145 8-bit Full HD at 23.98P, 25P, 29.97P, 50i and 59.94i.
Codec Board supports ProRes 4444*, ProRes 422 (HQ), ProRes 422, DNxHD 220x and DNxHD 145 at a variety of frame rates**
The CBK-55PD Codec Board supports the following recordings with the PMW-F55 and PMW-F5 cameras: ProRes 4444 12-bit Full HD at 23.98P*, 24P*, 25P* and 29.97P*: ProRes 422 (HQ) 10-bit Full HD and ProRes 422 10-bit Full HD at 23.98P, 24P, 25P, 29.97P, 50i, 59.94i, 50P* and 59.94P*; DNxHD 220x 10-bit Full HD and DNxHD 145 8-bit Full HD at 23.98P, 25P, 29.97P, 50i and 59.94i.
* Requires firmware update in 1H/2015.
** CBK-55PD must be fitted at a Sony Service Centre. Firmware update V5.0 is also required.
