SWIT PB-R160S+ 160Wh Heavy Duty Battery

Code: SWI/PB-R160S+
$635.00
The PB-R160S is a 160Wh V-mount battery, for Cine and ENG cameras, with a newly designed heavy duty housing and shock-proof design. The battery supports high load, fast charging and digital power info display, making it an ideal power solution for field applications.

ENQUIRE NOW

Got a question about this product?
Send us a message

In Stock

In stock - Ships in 1-2 days

Heavy Duty Battery

High load & IP54 waterproof

The PB-R160S+ is a 160Wh V-mount battery for Cine and ENG cameras with a dual housing heavy-duty sealed structure. It is IP54 rainproof, 1.5m drop-off proof with a digital power info display and supports high load, fast charging.

IP54 Waterproof

1.5 meters drop-off proof

The PB-R160S+ features a dual-housing sealed structure that supports IP54 waterproof in rain, snow and other inclement weather. The dual housing with rubber cover is strong enough to survive a drop from up to 1.5 meters.

160Wh / 11.1Ah Capacity

The largest capacity for airplane boarding

The PB-R160S+ consists of 18 high class 18650 battery cells, and reaches 160Wh / 11.1Ah high capacity - the largest capacity able to be taken aboard an airplane.

The PB-R160S+ can power a standard ENG camera for approx. 6 hours, and approx. 2 hours for the ARRI ALEXA.

6A Fast Charging

Using the SWIT S-3812S fast charger

The PB-R160S+ supports 6A fast charging when used with the  SWIT S-3812S fast charger, which saves more than 50% charging time. The 160Wh PB-R160S+ battery can be charged from 0 to 80% after 1.5 hours, and fully charged within 2.5 hours.

Digital Power Info

8-LED + Sony & RED viewfinder info

The PB-R160S+ has an innovative 8-LED power indicator system. When free or charging, the LEDs will indicate current capacity percentage. When the battery is discharging, the LEDs will display the remaining running time at the current discharging power, accurate to 15 minutes. The battery additionally adopts intelligent SMBUS which is  compatible with both SONY and RED camera info system, and so can display the remaining power time on the camera viewfinder.

D-tap Socket

A D-tap DC output socket is equipped on the top side of the battery pack to power the other on-camera equipment. The Max output current of D-tap is 10A.

Features

  • IP54 water/dust proof
  • Strong 1.5m drop proof
  • 14.4V, 160Wh capacity
  • 200W/16A constant high load
  • 6A fast charging support
  • 8-LED digital power indicators
  • SONY/RED viewfinder power info display
  • D-tap power output socket
  • V-mount connection
  • Multiple circuit protections

Specifications

Nominal Voltage 14.4V
Capacity 160Wh/11.1Ah
Constant load

200W / 16A

Max charging current 6A fast charging
IP class IP54
Mount Type

V-mount

Operation Temperature 0-40°C
Net weight

Approx 1.08kg

Dimensions 162×101×53mm
