Image Sensor
|
Sensor
|
Super 35mm type CMOS
|
System
|
RGB primary colour filter (Bayer array)
|
Total pixels per sensor
|
Approx. 9.84 megapixels (4206 x 2340)
|
Effective pixels per sensor
|
Approx. 8.85 megapixels (4096 x 2160): When 4096 x 2160 or 2048 x 1080 is selected as the resolution Approx. 8.29 megapixels (3840 x 2160): When 3840 x 2160 or 1920 x 1080 is selected as the resolution
|
Signal-to Noise Ratio
|
50.00 Hz mode: 53 dB (Typical) [3840x2160/25.00P, Canon Log 3 Base sensitivity ISO800 (Dynamic range 1600%),HDMI OUT]
|
Dynamic Range
|
15 Stops (CinemaRAW Light)13 Stops (MP4/Canon Log3)
|
Image Processor
|
Type
|
Dual DIGIC DV6
|
Lens
|
Lens Mount
|
Canon EF Mount
|
Lens Magnification Factor (for EF Mount lenses, including Cinema Primes)
|
At 4096 x 2160 or 2048 x 1080 resolution: Actual focal length x approx. 1.460 At 3840 x 2160 or 1920 x 1080 resolution: Actual focal length x approx. 1.534
|
Changeable Lens Mount
|
Yes, mount change to PL mount possible via Canon Service centre (Paid for service)
|
Peripheral illumination correction
|
Yes with compatible lenses
|
ND filter
|
Clear,2,4,6,8,10-stop
|
Focus control
|
Manual via lens, manual via RC-V100 Auto Focus (Dual Pixel AF Approximately 80%(vert.),80%(horiz.))
|
Iris control
|
Manual Via camera body or RC-V100, fine, 1/2 or 1/3 step increments, Auto (with compatible lenses), Push Auto Iris
|
Image stabilization system
|
Depends on lens used
|
Recording
|
RAW Recording options
|
RAW (Cinema RAW Light)
|
Internal Recording
|
Cinema RAW Light, MP4
|
Recording time (CFast 2.0™card)
|
128GB card 15 Mins (4K Cinema RAW Light 1Gbps VBR)
|
Recording time (SD Card)
|
128GB card 110 mins (MP4, 150Mbps) 485Mins (MP4, 35Mbps)
|
Recording Formats
|
Cinema RAW Light, (CFast 2.0™¹) MP4 XF-AVC (SD card. XF-AVC²)
|
Recording Frame Rate
|
(1) 59.94 Hz mode (59.94P/29.97P/23.98P) (2) 50.00 Hz mode (50.00P/25.00P) (3) 24.00 Hz mode (24.00P)
|
Slow/Fast motion
|
YES
|
Interval Record
|
YES
|
Frame Record
|
YES
|
Pre Record (cache record)
|
YES, 3 seconds
|
Relay Recording
|
YES, SD Card recording only
|
Double Slot (simultaneous) Recording
|
YES, SD Card recording only
|
Scan Reverse
|
NO
|
HD->SD conversion
|
NO
|
Photo storage media
|
SD Card
|
Photo Recording Size
|
2048x1080 (when video image resolution is 4096x2160/2048x1080) 3840x2160 (when video image resolution is 3840x2160) 1920x1080 (when video image resolution is 1920x1080)
|
System
|
Wave Form Monitor
|
YES
|
Colour Bars
|
YES, SMPTE / EBU / ARIB
|
Peaking
|
YES
|
Zebra
|
YES. Zebra 1 Level 5 ±5% to 95 ±5% in 5 percentage point intervals (70 ±5%) Zebra 2 Level: 0% to 100% in 5 percentage point intervals (100%)
|
Markers
|
YES, Centre, Horizontal, Grid Aspect Ratio(4:3 / 13:9 / 14:9 / 16:9 / 1.375:1 / 1.66:1 / 1.75:1/1.85:1 / 1.90:1 / 2.35:1 / 2.39:1 / Custom), Safe Area (80% / 90% / 92.5% / 95%)
|
EVF
|
Built- In EVF
|
YES. 1.77M dots
|
Optional EVF Accessory
|
Canon EVF-V70 (Also requires CL-V2 bracket)
|
Display Panel
|
Display Panel
|
4 inch/10.1cm diagonal LCD Monitor. Touch panel. Approx., 1.23M dots
|
