AJA UltraHD/HD 10GigE IP to HDMI Converter

Code: BLO/AJA-IPR-10G2-HDMI

IPR-10G2-HDMI provides monitoring of UltraHD and HD SMPTE 2110 signals across 10 GigE to a HDMI ouput.

For purchasing information

Enquire Now

Overview

IPR-10G2-HDMI is a SMPTE ST 2110 video and audio receiver featuring new dual 10 GigE SFP+ cages that provide hitless switching for redundancy protection in critical distribution and monitoring applications and support for bridging UltraHD or HD signals over IP to HDMI.

The IPR-10G2-HDMI supports monitoring of SMPTE 2110 signals via HDMI up to UltraHD 30p and HD 60p. It also features a reference-in via BNC for seamless integration into existing baseband environments such as master control, trucks or edit suites. IPR-10G2-HDMI includes a full-size HDMI 1.4b video output with embedded eight-channel audio output.

Monitor ST 2110 Video and Audio from anywhere on the Network.

The IPR-10G-HDMI is a SMPTE ST 2110 to HDMI Mini-Converter suited for point-of-use applications including source monitoring and an HDMI feed to compatible devices.

The AJA IPR-10G-HDMI receives SMPTE ST 2110 IP video and audio, then formats the data for output on a full size HDMI 1.4b interface.

With 3G/1.5G-SDI routers often at capacity while facilities await their transition to IP, there is a huge benefit in being able to send video sources from a feed, camera, router or edit bay via IP and provide HDMI monitoring at the destination.

The audio associated with the video stream is extracted, synchronized, and then embedded into the HDMI interface as well as output on an analog RCA interface.

User Control

IPR-10G2-HDMI provides two key methods for control. The Control LAN Ethernet port enables control of the Mini-Converter from web browsers on any platform and REST clients. The mini-USB connector facilitates quick and simple initial network configuration, and firmware updates.

1x RJ-45 (IEC 60603-7) for 10/100/1000 Base-T Ethernet (IEEE 802.3-2012)
HTTP/1.1 (RFCs 7230, 7231, 7232, 7233, 7234, 7235)
Web and REST clients supported
1x USB 2.0 Mini-B (IEC 62680-1) connector
AJA eMini-Setup of network parameters

Workflow

IPR-10G2-HDMI provides HDMI output from SMPTE ST 2110 video and audio over IP streams. Combine your IPR-10G2-HDMI units with AJA KONA IP for HD (I/O card for use in desktop workstations) or receive UltraHD or HD from servers and more to instantly create a real-world ST 2110 workflow for video over IP production and monitoring.

Features

SMPTE 2110 audio, video receiver
Supports UltraHD up to 30p and HD up to 60p, YCbCr 4:2:2
Rugged, fanless design
2x 10 GigE SFP+ cages for media LAN (providing support for "hitless switching) with status light
1x 1 GigE RJ45 socket for control LAN with status light
Dedicated HDMI receiver with full size HDMI 1.4b video port
Full 10-bit pixel processing pipeline
Embedded HDMI audio output (up to eight channels)
2x RCA analog audio output
1x BNC Reference In
1x mini-USB port for initial network configuration with AJA eMini-Setup software
Complete control interface on any web browser from a built-in webserver
Customizable control with AJA REST API
5-year international warranty and support
