AJA

AJA 3G-SDI 8-Channel 24-bit AES Embedder/Disembedder openGear Card

Item Code: BLO/AJA-OG-3G-AMD

The OG-3G-AMD is a state of the art, openGear compatible, 8-channel AES audio embedder/disembedder with support for 3G-SDI input and output up to 1080p 60. Simple user controls allow channel enabling and mapping. A 10x BNC rear openGear connector module is included.

RRP: 0   Save:

For purchasing information

Key Features

  • Video Formats: 3G-SDI
  • 3G-SDI Embedder / Disembedder in one board
  • Input: 1x 3G-SDI BNC
  • Outputs: 1x 3G-SDI BNC
  • 4x AES BNC (2 channels per input)
  • Local and Remote modes
  • Incoming embedded audio passed, removed, or overridden
  • Configure via openGear DashBoard, or DIP switch
  • Power: 5.0 watts
  • Hot swappable
  • Compatible with OGX, OG3 and DFR-8321 openGear frames

The OG-3G-AMD is a state of the art, openGear compatible, 8-channel AES audio embedder/disembedder with support for 3G-SDI input and output up to 1080p 60. Simple user controls allow channel enabling and mapping. A 10x BNC rear openGear connector module is included.

Designed for use in high density openGear 2RU frames including AJA’s OG-X-FR frame, new DashBoard software support on Windows, macOS and Linux offers remote control and monitoring of the openGear architecture and provides convenient and industry standard configuration, monitoring and control options over a PC or local network.

openGear Overview

For critical broadcast applications, AJA openGear compatible converter cards provide the highest levels of quality and reliability for use in openGear frames including the new AJA OG-X-FR. AJA offers cards for infrastructure, HDMI/SDI conversion, Fiber conversion and scaling. All new AJA openGear are DashBoard software compatible, allowing easy configuration and control.

openGear Compatibility

The openGear standard ensures that AJA cards will be compatible with other openGear products from certified openGear partners. With a growing list of products, openGear is the future of rackframe products.
