Autocue Pioneer Studio Box Lens Mounting

Code: ADE/AU-P7011-0900
$6,670.00

This mounting kit includes all the hardware needed for a studio box lens teleprompter, including hood, monitor mount, telescopic fixing rods and glass.

Add to Cart

This item is already in your cart, click here to update quantities.

ENQUIRE NOW

Got a question about this product?
Send us a message

Special Order Item

Usually ships in 1-2 weeks

Request ETA

What's In The Box?

  • Studio lens hood assembly
  • Mounting bracket
  • Monitor spine
  • Telescopic rods
  • Beamsplitter glass
  • This mounting kit includes all the hardware needed for a studio box lens teleprompter, including hood, monitor mount, telescopic fixing rods and glass.

    If the 19″ Pioneer Studio Box Lens Teleprompter doesn’t quite match your needs, you can combine this kit with the Autocue monitor of your choice to create a complete teleprompter compatible with box lenses. The mounting kit fits to the front of larger camera supports using telescopic rods instead of the standard rail underneath the camera.

    Key Features

    • Mounting kit for Autocue monitors
    • Extra-large hood opening fits any box lens
    Specifications
    Counterweight5 kg11.02 lb
    Counterweight Mounting Rods2x 19mm dia.2x 19mm dia.
    Max Monitor Size24" 16:9 widescreen24" 16:9 widescreen
    Max Monitor Weight5 kg11.02 lb
    Monitor FixingVESA100VESA100
    Monitor Fixing Positions5 (20mm pitch)5 (20mm pitch)
    Mounting Dimensions12 cm x 25.3 cm x 35.4 cm4.72 in x 9.96 in x 13.94 in
    Mounting Weight6100 (excluding counterweight)6100 (excluding counterweight)
    Rail Fixings3/8"-16, with optional 1/4"-20 inserts3/8"-16, with optional 1/4"-20 inserts
    Tilt Positions2 (plus stowed)2 (plus stowed)
