Zaxcom TRXCL3.5 Camera Link Transmitter

Code: ZAX/TRXCL3.5

The TRXCL3 offers superb sound quality, a compact design and incredible ease of use of for those in film, television or ENG applications. Weighing less than a half pound (7.3 oz) it features internal recording, encrypted audio, timecode, ZaxNet™ functionality and more.

Available in two frequency options:

".5 band” (512-614 MHz)
“.6 band” (596-698 MHz)

For purchasing information

Enquire Now

Overview
Specifications

As a wide-band transmitter, it’s capable of sending audio with embedded timecode to camera through its UHF signal to QRX200, RX200 and QRX235 Zaxcom receivers and via ZaxNet™, a 2.4 GHz signal, to an ERX3TCD receiver.

Audio is 100% digital and fully encrypted to keep transmissions private. The transmitter is also immune to intermodulation which occurs when multiple transmitters in close proximity to each other mix together.

The TRXCL3 can simultaneously transmit and record internally to a microSD card. Files are saved using the highly reliable lossless MARF (Mobile Audio Recording Format) and can then be instantly converted to Broadcast Wave Format (BWF) or MP3 via ZaxConvert, free software available for MAC or PC.

The unit features a single TA5 audio input that can be used as balanced stereo line level or sample rate converting AES. A 3.5mm output allows for audio out and a BNC connector provides a connection for timecode in or out. An OLED display lets users easily navigate the intuitive menu.

Additionally, the TRXCL3 is equipped with ZaxNet™ to send or receive timecode, scratch track audio and remote control commands. Zaxcom High Density (ZHD) modulation has been added to increase the number of channels in the wireless spectrum.

FEATURES

DESIGN MATTERS

Deliver pristine audio quality with the TRXCL3 wide-band camera link transmitter for sound professionals in film, television or ENG applications.

Weighing 7.3 oz, it’s constructed from an impact resistant metal casing that’s cool to the touch. A bright OLED display provides easy menu navigation.

CONNECTIVITY

The TRXCL3 sends audio with embedded timecode to camera via a UHF signal to QRX200, RX200 and QRX235 receivers or through ZaxNet’s 2.4 GHz signal to an ERX3TCD receiver.

A TA5 audio input offers balanced stereo line level or sample rate converting AES. The 3.5mm output delivers audio and the BNC connector provides timecode in our out.

ENCRYPTED AUDIO

The TRXCL3 transmits using 100% digital modulation and audio is fully encrypted to keep recordings private.

INTERNAL RECORDING

Audio can be simultaneously transmitted and internally recorded to a microSD card using MARF (Mobile Audio Recording Format) which eliminates file corruption common to recordings due to loss of power or early card removal.

BETTER WORKFLOW

The TRXCL3 is designed to limit intermodulation which can occur when multiple transmitters are in close proximity to each other and mix together.

ADVANCED FEATURES

ZaxNet allows you to send or receive timecode, scratch track audio and remote control commands. Zaxcom High Density (ZHD) modulation increases the number of available channels in the wireless spectrum.

MHZ BANDS

Available in two frequency options:

“.5 band” (512-614 MHz) or “.6 band” (596-698 MHz)

Specifications

Transmitter

RF Modulation	Proprietary Digital Method
TRXCL3.5 RF Frequency Range	512 - 614 MHz
TRXCL3.6 RF Frequency Range	596 - 698 MHz
RF Frequency Step	100 KHz
RF Bandwidth in ZHD Mode	50 KHz
RF Bandwidth	200 KHz
Channel Separation in ZHD Mode	As close as 100 KHz (receiver dependent)
Channel Separation in XR Mode	400 KHz
Antenna Connector	50 Ω SMA Female
Emission Designator	180 KV2E
FCC Part	74.861

Transmitter Audio

Dynamic Range	114 dB
Distortion	0.002%
Frequency Response	Mode 020 Hz to 16 kHz / T & M Mode 0.2 Hz to 16 kHz
System Group Delay	3.5 ms
Audio input connector	TA5 male
Analog Input Range	-10 to +4 dBu
Analog input type	Balanced Line Level
Audio input Impedance	4.7 k Ω
ADC Bit-Depth	24 Bits
ADC Sampling-Rate	48 kHz
AES input	Balanced with Sample Rate Conversion
Sample rate range	32 Khz to 96 Khz

Timecode Reader / Generator

Clock Accuracy	1.54 PPM (1 Frame Out in 6 Hours)
Timecode Type	SMPTE
Timecode Frame-Rates	23.98, 24, 25, 29.97NDF, 29.97DF, 30NDF, 30DF

Internal Recording

Media	MicroSD Card (Flash Memory)
File Format	.ZAX
Recording Time	96 Hours (16 GB Card)

2.4 GHz ZaxNet Transceiver

RF Frequency Range	2.403 to 2.475 GHz
RF Modulation	Digital Spread Spectrum
RF Frequency Step	0.001 GHz (1 MHz)
RF Bandwidth	1 MHz
Channel Separation	2 MHz
Sensitivity	-96 dBm
RF power output	TBD

Physical / Power

Weight	7.3 oz
Dimensions (H x W x D)	1”x 3.55” x 3.23”
Display	Graphic OLED
Power Output	25 / 50 / 100 mW – Software Selectable
Power consumption	2.13 watts
