Venus Optics Laowa 24mm T14-40 Full Frame 2x PeriProbe Cine Lens (EF Mount)

Code: RAD/VE2414P-EF

The Venus Optics LAOWA 24mm T14-40 Full Frame 2x PeriProbe Cine Lens captures sharp magnified shots with full frame camera sensors using their Canon EF-mount and has a focal length of 24mm.

For purchasing information

Enquire Now

The Venus Optics LAOWA 24mm T14-40 Full Frame 2x PeriProbe Cine Lens captures sharp magnified shots with full frame camera sensors using their Canon EF-mount and has a focal length of 24mm. Its periscope-style lens tube with interchangeable ends features an aperture range of T14 to T40 for a deep or shallow depth of field. Use it underwater or in tight spaces, thanks to its waterproof front barrel and slim profile.

A lens construction of 28 elements in 19 groups creates a smooth, circular bokeh with minimal focus breathing. The lens can rotate 360° along the axis to unlock the orientation ring and create spinning shots. Both the focus and iris rings have 0.8 MOD cinema-standard gears for intuitive manual controls. A 1/4"-20 thread at the end of the 15.7" lens allows you to mount fill lights or other accessories. Built-in LEDs in the lens tips provide a ring-light effect to your shots.

Key Features

  • Maximum T14 aperture for greater depth of field at close distances
  • Cinema industry-standard 0.8 MOD focus and iris gears compatible with follow focus and iris controls
  • Manually focus on objects only 0.8" away at 2x magnification
  • Lens construction of 28 elements in 19 groups for smooth, circular bokeh
  • A wide 85° perspective to create a "bug-eye" effect
  • Long 15.7" lens barrel for access to tight spaces, stay a safe distance from subjects
  • Waterproof front barrel for underwater shots without requiring a waterproof housing
  • 360° rotation with a clutch mechanism to adjust the orientation ring
  • Switch between 90° periscope to straight probe
  • 1/4"-20 thread for mounting of fill lights
Specifications
Focal Length 24mm
Lens Mount Canon EF
Lens Format Coverage Full Frame
Maximum Aperture T14
Minimum Aperture T40
Diagonal Angle of View Full Frame: 85°
Horizontal Angle of View Full Frame: 85°
Minimum Focus Distance From Unspecified Point in Lens: 0.8" / 2 cm
Optical Design 28 Elements in 19 Groups
Diaphragm Blades 7
Gear MOD & Pitch Focus: 0.8 MOD / 32 Pitch
Iris: 0.8 MOD / 32 Pitch
Front Diameter 61 mm
Filter Thread No
Focus Rotation 360°
Iris Rotation 360°
Zoom Rotation 360°
Tilt Rotation 45°
Zoom Ratio 2x
Image Stabilization No
Lens Support No
Length 16.1" / 408 mm
Weight 27.2 oz / 770 g>
