Video |
Video Inputs |
1x HDMI Type A receptacle (non-HDCP sources)
1x 3G-SDI (75 Ω BNC) |
Bonding |
Bonding |
Simultaneous bonding over up to 8 network ports:
2 x VidiU Nodes
WiFi
ethernet
Up to 4 cellphones (iPhones or Android)
Requires Core or Sharelink subscription. |
Supported Resolutions |
Supported Resolutions |
1080p 23.98/24/25/29.97/30/50/59.94/60
1080i 50/59.94/60
720p 50/59.94/60
576i/50
576p/50 (HDMI only)
480i/59.94/60
480p/59.94/60 (HDMI only) |
Video Processing |
Video Compression |
H.264: base/main/high profile up to level 4.2
H.265: main profile up to level 4.1 |
Supported Video Bitrate |
500 Kbps to 12 Mbps |
Supported Video Bitrate Details |
Best Quality: 12 Mbps + 256 kbps audio
HD+: 8 Mbps + 256 kbps audio
HD: 5 Mbps + 192 kbps audio
High: 3 Mbps + 192 kbps audio
Medium: 1.5 Mbps + 128 kbps audio
Low: 800 kbps + 128 kbps audio
Mobile: 500 kbps + 96 kbps audio |
Graphics |
Title
Scoreboard
Timer
Bugs/watermarks/logos |
Test Pattern Generator Support |
Yes |
Video Format Conversion Support |
Built-in Video Scaler and DeInterlacer |
Color Correction |
None |
Protocol Support |
Network Protocols |
TCP/IP, UDP, HTTP, DHCP, NTP, SSL, IGMP |
Supported Video Transport Protocols |
RTMP, Live:Air |
Software Or Platform Integration |
Facebook, YouTube Live, Vimeo, Persicope, Twitch, Wowza, Ustream, and Livestream |
Audio Processing |
Audio Compression |
Audio compression: AAC-LC |
Supported Audio Bitrate Details |
TBD |
Inputs |
Audio Input |
Embedded HDMI audio input, 2-Channel/Unbalanced,
Embedded SDI audio input, 2-Channel/Unbalanced,
3.5mm TRS analog line-in |
Outputs |
Audio Output |
3.5mm TRRS headphone output/mic-in, adjustable volume |
Physical |
Dimensions |
4.9" W x 3.1" D x 1.3" H [124 x 80 x 33mm] |
Weight |
13.6oz [386g] |
Construction |
Machined aluminum and ABS Plastic |
Mountability |
1/4" 20 mounting hole with hotshoe adapter |
>Interfaces |
Http |
WebUI for Configuration and Control |
Configuration Interfaces |
OLED display with joystick navigation buttons
Feature-rich WebUI for configuration and control |
Switches |
On/Off and reset switch |
Recording Storage |
Micro SD/SDHC (classs 6 and above) formatted FAT32,
USB formatted FAT32 |
Mobile App |
VidiU App for iOS and Android devices |
Usb Interface Functionality |
2x powered USB 2.0 host ports |
Network |
Ethernet |
RJ45, 10/100 BASE-T |
Wireless |
WiFi: Dual Band MIMO 802.11 ac/a/b/g/n |
Usb |
2 x USB for 3G/4G modem support |
Rf Channel Selection |
Auto with 3 modes: (2.4 or 5 GHz), Auto (2.4 GHz only), Auto (5 GHz only)
Manual: Configurable to specific channels |
Power |
Power Input |
USB-C connector
Power adaptor and USB-C cable included |
Battery |
Internal Rechargeable Li-polymer Battery (3.7V, 5000mAh),
up to 2.5 hour duration (streaming over WiFi) |
Nominal Power Consumption |
6.5W (while charging: up to 10W) |
