Panasonic AU-EVA1 Super 35 Cinema Camera Body

Code: GEC/AU-EVA1EN8
$9,275.00
Featuring a newly designed 5.7K Super 35mm sensor, the compact and lightweight AU-EVA1 is tailor-made for handheld shooting, but also well suited for documentaries, events, commercials, and music videos.
Add to Cart

Found this item cheaper elsewhere? Let us know

ENQUIRE NOW

Got a question about this product?
Send us a message

Out of Stock - Call for availability

Or get notified when back in stock

OK, we'll notify you when Panasonic AU-EVA1 Super 35 Cinema Camera Body is back in stock.

The EVA-lution of the Panasonic Cinema Camera Line-Up



Compact and lightweight, the AU-EVA1 is tailor-made for handheld shooting, but also well suited for documentaries, events, commercials, and music videos. “For cinema-style acquisition, we realized there was a space between the GH5 and the VariCam LT. With its compact size and new 5.7K sensor, the EVA1 fills that gap for a variety of filmmaking applications.” - Cinema Product Manager Mitch Gross



Cinematic Run & Gun

Weighing only 2.6 lbs (1.2 kg / body) with a compact form factor (6.69” x 5.31” x 5.23”) and a removable handgrip, EVA1 can be used for efficient handheld shooting applications and can also be mounted on a drone, gimbal rig, or jib arm for complex yet smooth camera moves. There will also be numerous mounting points and Panasonic is currently working with top accessory makers to allow further customization with the EVA1.



5.7K Super 35mm Sensor

The EVA1 contains a newly designed 5.7K Super 35mm-sized sensor for capturing true cinematic images. By starting at a higher native resolution, the 5.7K sensor yields a higher resolving image when down sampled to 4K, UHD, 2K, and even 720p. The increased color information results in a finer, more accurate finished image.



Dual Native ISO

One of the key features of the VariCam 35, VariCam LT, and VariCam Pure is Dual Native ISO. Utilizing a process that allows the sensor to be read in a fundamentally different way, Dual Native ISO extracts more information from the sensor without degrading the image. This results in a camera that can switch from a standard sensitivity to a high sensitivity without an increase in noise or other artifacts. The EVA1 will include Dual Native ISO*.



V-Log / V-Gamut

The ability to capture accurate colors and rich skin tones is a must for any filmmaker. Like the VariCam lineup of cinema cameras, the EVA1 contains V-Log/V-Gamut capture to deliver high dynamic range and broad colors. V-Log has log curve characteristics that some would say are reminiscent of negative film and V-Gamut delivers a color space even larger than film. The EVA1 will also import the celebrated colorimetry of the VariCam line.



EF-Mount Lenses

The EVA1 utilizes a native EF-mount, giving shooters access to the broad EF lens ecosystem, including dozens of cinema-style prime and zoom lenses from numerous manufacturers.



E.I.S. & Integrated ND Filters

Electronic Image Stabilization (EIS) is employed to compensate for camera shake and blurring, which will help smooth out handheld or shoulder-mount shots on documentary or run-and-gun projects. Behind the lens mount, an integrated ND filter wheel in 2, 4, and 6 stops allows for precise exposure control. The EVA1 also allows the IR Cut filter to be swung out of the path to the sensor at the push of a button. Unique photographic effects and night vision imagery are possible with this control over infrared.



Low-Cost Media / SD Card Recording

Ideal for indie filmmakers, the EVA1 records to readily-available, lower-cost SD cards. The camera can record in several formats and compression rates, and offers up to 10-bit 4:2:2, even in 4K. For high-speed capture, the EVA1 offers 2K up to 240-fps. In terms of bitrates, you can record up to 400-Mbps for robust recording. A complete breakdown of recording formats will be available at the time of the EVA1’s release.



Professional Features

As a professional video production tool, the EVA1 offers dual balanced XLR audio inputs and 4K-capable video outputs in both HDMI and SDI. In a future firmware upgrade, EVA1 will offer 5.7K RAW output to 3rd party recorders.

*The final ISO specifications for the EVA1 will be announced Fall 2017.

Specifications

General Specification

Power DC 7.28 V (Battery Operation)
DC 12 V (AC adapter operation)
Power Consumption 19 W (with LCD/HDMI/SDI ON)
Operating Temperature 0 °C to 40 °C (32°F to 104°F)
Operating Humidity 10% to 85% (relative humidity)
Storage Temperature -20 °C to 60 °C (-4°F to 140°F)
Weight Body: Approx. 1.2 kg (2.65 lb) (excluding accessories)
Shooting: Approx. 2.05 kg (4.52 lb) (with accessories)
Dimensions 135 mm (W) x 133 mm (H) x 170 mm (D) (excluding protrusions and accessories)
(5-5/16 inches x 5-1/4 inches x 6-11/16 inches)

Camera Unit

Image Sensor Super 35 mm, MOS sensor
Number of Pixels Total pixels: Approx. 20.49 megapixels, 6340 (H) x 3232 (V)
Effective pixels: Approx. 17.25 megapixels, 5720 (H) x 3016 (V)
Sensor Area and Max Frame Rate S35: 4K/UHD 60 fps/50 fps
2K/HD 120 fps/100 fps
4/3": 2K/HD 240 fps/200 fps
Latitude 14 stop
Log V-Log
Gamma eV-Look Gamma (2 types)
Video Gamma
Hybrid Log Gamma (HLG)
Gamut V-Gamut (V-Log)
EI Settings [ISO] mode: NATIVE ISO: 800, 2500
800 Base: 200 to 2000
2500 Base: 1000 to 25600
[dB] mode: (Normal) -12 dB to 8 dB
(High) -8 dB to 20 dB
Shutter Speed [deg] mode: 1.0 deg to 358 deg (0.5 deg step)
12 presets
[sec] mode: 1/24.1 sec to 1/8000 sec (23.98p)
12 presets
Color Temp ATW, AWB, 2000 K to 15000 K ±10.0 GMg
12 presets
Lens Mount EF mount
Image Stabilization Electric Image Stabilization (EIS)
Auto Focus One push auto focus
ND Filter CLEAR, 0.6ND, 1.2ND, 1.8ND, Electrical driven
IR Cut Filter USER assignable IR shooting (filter ON/OFF)

Memory Card Recorder

Recording Media SDHC memory card (4 GB to 32 GB)
SDXC memory card (32 GB to 128 GB)
UHS-â… /UHS-â…¡ UHS Speed Class3 is supported,
Video Speed Class V90 is supported
Recording Slot SD memory card slot x 2
Recording Resolution 4096 x 2160 (4K), 3840 x 2160 (UHD),
2048 x 1080 (2K), 1920 x 1080 (FHD),
1280 x 720 (HD)
Recording System Frequency 59.94p, 50p, 29.97p, 25p, 24p, 23.98p
59.94i, 50i (AVCHD only)
2slot Functions Simul Rec, Relay Rec, Loop Rec*1,
Background Rec*1
Other Rec Functions Pre Rec, Interval Rec*1, One Shot Rec*1

Digital Video

Quantizing MOV: 4:2:2 10 bit/4:2:0 8 bit
AVCHD: 4:2:0 8 bit
Video Compression Format H.264/MPEG-4 AVC High Profile

Digital Audio

Recording Audio Format MOV: 48 kHz/24 bit, 2 CH, Linear PCM
AVCHD: 48 kHz/16 bit, 2 CH, Dolby Audio™
Headroom 18 dB/20 dB (menu switchable)

Video Output

SDI OUT 0.8 V [p-p], 75 Ω, 4K (6G), HD (3G/1.5G)
Output format (4:2:2 10 bit):
  • 4096 x 2160: 29.97p, 25p, 24p, 23.98p
  • 3840 x 2160: 29.97p, 25p, 24p, 23.98p
  • 1920 x 1080: 59.94p, 50p, 59.94i, 50i, 29.97p, 29.97PsF, 25p, 25PsF, 24p, 24PsF, 23.98p, 23.98PsF
  • 1280 x 720p: 59.94p, 50p
RAW* output format (10 bit):
  • 5760 x 3072: 29.97p, 25p, 24p, 23.98p
  • 4096 x 2160: 59.94p, 50p, 29.97p, 25p, 24p, 23.98p
HDMI HDMI x 1, TypeA, HDMI REC REMOTE is supported,
Viera Link is NOT supported
Output format (4:2:2 10 bit):
  • 4096 x 2160: 59.94p, 50p, 29.97p, 25p, 24p, 23.98p
  • 3840 x 2160: 59.94p, 50p, 29.97p, 25p, 24p, 23.98p
  • 1920 x 1080: 59.94p, 50p, 59.94i, 50i, 29.97p, 25p, 24p, 23.98p
  • 1280 x 720: 59.94p, 50p
  • 720 x 480: 59.94p
  • 720 x 576: 50p
Output format (4:2:0 8 bit):
  • 4096 x 2160: 59.94p, 50p
  • 3840 x 2160: 59.94p, 50p

Audio Input/Output

Internal Mic Stereo microphone
INPUT1/2 XLR (3-pin) x 2 (INPUT1/2), input high impedance, LINE/MIC/MIC +48 V (menu switchable)
MIC: −40 dBu/−50 dBu/−60 dBu (menu switchable)
LINE: +4 dBu/0 dBu (menu switchable)
SDI OUT Linear PCM 2 CH
HDMI Linear PCM 2 CH
PHONES 3.5 mm stereo mini jack x 1
Speaker 20 mm diameter, round x 1

Other Input/Output

TC IN/OUT BNC x1 for IN/OUT (menu switchable)
IN: 1.0 V [p-p] to 4.0 V [p-p], 10 kΩ
OUT: 2.0 V [p-p] ±0.5 V [p-p], low impedance
LCD 40-pin (Dedicated)
REMOTE 2.5 mm Super Mini Jack
USB 2.0 (HOST) Type-A, 4-pin for Wireless Module (AJ-WM50)
EF Mounting Contact 8-pin
DC IN 12 V DC 12 V (10.5 V to 13.5 V) EIAJ type 4

LCD Monitor

Size 3.5-type LCD monitor (approx. 1,150,000 dots)
Touch panel (MENU control, Shooting assist functions)
Switches MIRROR (OFF, B/T, ROTATE)

Hand Grip

Mounting Mechanism One touch rotatable/Detachable
Switches REC, MENU/IRIS dial, User switch x 2

Included Accessories

Accessories Battery (5900 mAh), Battery charger, AC adapter, AC cable, Shoulder strap, Microphone holder, Microphone holder adapter, LCD monitor (with hood and mounting attachment), Handle, Grip, Grip belt, Mount cap

*1: Functions to be supported by firmware update.

* Dolby, Dolby Audio, and the double-D symbol are trademarks of Dolby Laboratories.

* Specifications are subject to change without notice.

Recording Format and Recording Time

Format Pixel Main Codec (bps) Frequency Sampling Bitrate
(average)		 Recording Time
(128 GB)
MOV* 4096 x 2160 (4Ｋ) 422Intra 400M Update 29.97p, 24p, 25p, 23.98p 4:2:2 10 bit 400 Mbps (VBR) Approx. 40 min.
422LongGOP 150M 29.97p, 24p, 25p, 23.98p 4:2:2 10 bit 150 Mbps (VBR) Approx. １ hour 50 min.
420LongGOP 150M 59.94p, 50p 4:2:0 8 bit 150 Mbps (VBR) Approx. １ hour 50 min.
420LongGOP 100M 29.97p, 24p, 25p, 23.98p 4:2:0 8 bit 100 Mbps (VBR) Approx. 2 hours 40 min.
3840 x 2160 (UHD) 422Intra 400M Update 29.97p, 25p, 23.98p 4:2:2 10 bit 400 Mbps (VBR) Approx. 40 min.
422LongGOP 150M 29.97p, 25p, 23.98p 4:2:2 10 bit 150 Mbps (VBR) Approx. １ hour 50 min.
420LongGOP 150M 59.94p, 50p 4:2:0 8 bit 150 Mbps (VBR) Approx. １ hour 50 min.
420LongGOP 100M 29.97p, 25p, 23.98p 4:2:0 8 bit 100 Mbps (VBR) Approx. 2 hours 40 min.
2048 x 1080 (2Ｋ) 422Intra 200M Update 59.94p, 50p 4:2:2 10 bit 200 Mbps (VBR) Approx. １ hour 20 min.
422Intra 100M Update 29.97p, 24p, 25p, 23.98p 4:2:2 10 bit 100 Mbps (VBR) Approx. 2 hours 40 min.
422LongGOP 100M 59.94p, 50p 4:2:2 10 bit 100 Mbps (VBR) Approx. 2 hours 40 min.
422LongGOP 50M 29.97p, 24p, 25p, 23.98p 4:2:2 10 bit 50 Mbps (VBR) Approx. 5 hours 20 min.
420LongGOP 100M 59.94p, 50p 4:2:0 8 bit 100 Mbps (VBR) Approx. 2 hours 40 min.
420LongGOP 50M 29.97p, 24p, 25p, 23.98p 4:2:0 8 bit 50 Mbps (VBR) Approx. 5 hours 20 min.
1920 x 1080 (FHD) 422Intra 200M Update 59.94p, 50p 4:2:2 10 bit 200 Mbps (VBR) Approx. １ hour 20 min.
422Intra 100M Update 29.97p, 24p, 25p, 23.98p 4:2:2 10 bit 100 Mbps (VBR) Approx. 2 hours 40 min.
422LongGOP 100M 59.94p, 50p 4:2:2 10 bit 100 Mbps (VBR) Approx. 2 hours 40 min.
422LongGOP 50M 29.97p, 25p, 23.98p 4:2:2 10 bit 50 Mbps (VBR) Approx. 5 hours 20 min.
420LongGOP 100M 59.94p, 50p 4:2:0 8 bit 100 Mbps (VBR) Approx. 2 hours 40 min.
420LongGOP 50M 29.97p, 25p, 23.98p 4:2:0 8 bit 50 Mbps (VBR) Approx. 5 hours 20 min.
AVCHD 1920 x 1080 (FHD) PS 59.94p, 50p 4:2:0 8 bit 25 Mbps (VBR) Approx. 11 hours
PH 23.98p, 59.94i, 50i 4:2:0 8 bit 21 Mbps (VBR) Approx. 12 hours 30 min.
HA 59.94i, 50i 4:2:0 8 bit 17 Mbps (VBR) Approx. 17 hours
1280 x 720 (HD) PM 59.94p, 50p 4:2:0 8 bit 8 Mbps (VBR) Approx. 35 hours

Update = Functions to be supported by firmware update.

* SDXC memory card is required for MOV recording.

Available Memory Card

Format Memory Card Type Bitrate/Recording Function Speed Class
MOV SDXC 400 Mbps Update Video Speed Class V60
or faster
2K/FHD VFR Mode*
Intra Codec Update
200 Mbps  Update Video Speed Class V30
UHS Speed Class 3
or faster
150 Mbps
100 Mbps
2K/FHD VFR Mode*
LongG Codec
50 Mbps Video Speed Class V10
UHS Speed Class 1
Speed Class 10 or faster
AVCHD SDHC/SDXC All Speed Class 4 or faster

Update = Functions to be supported by firmware update.

* VFR: Variable Frame Rate

Available Battery Pack

Battery Voltage/Capacity Charge time*
AG-VBR59
(Bundled)		 7.28 V
5900 mAh/43 Wh		 Approx. 3 hours 20 min.
AG-VBR89G 7.28 V
8900 mAh/64 Wh		 Approx. 4 hours
AG-VBR118G 7.28 V
11800 mAh/86 Wh		 Approx. 4 hours 40 min.
VW-VBD58 7.2 V
5800 mAh/42 Wh		 Approx. 5 hours 20 min.

* When using bundled battery charger.

* Specifications are subject to change without notice.
