Blackmagic DeckLink Quad HDMI

Item Code: NMA/BDLKDVQDHDMI4K

DeckLink Quad HDMI Recorder is a high performance PCIe card that lets you capture from 4 different HDMI sources in any combination of SD, HD, Ultra HD, 4K and even computer formats, all at the same time!

RRP: 0   Save:

For purchasing information

What's In The Box?

  • DeckLink Quad HDMI Recorder
  • SD card with software and manual

DeckLink Quad HDMI Recorder is a high performance PCIe card that lets you capture from 4 different HDMI sources in any combination of SD, HD, Ultra HD, 4K and even computer formats, all at the same time! Featuring 4 independent HDMI 2.0b input connections, DeckLink Quad HDMI is like getting 4 separate and customizable capture cards in one, making it perfect for software live switching, real time computer game capture, streaming and more!

Specifications

Supported Operating Systems macOS 10.13, 10.14 or Later
Windows 7, 8.1, 10 (All 64-Bit)
Linux
Inputs/Outputs 4 x HDMI 2.0b
Computer Interface PCI Express 8 Lane Generation 3 (Compatible with 8 and 16 Lane PCI Express Slots)
Audio Channels 8 x Embedded (HD and SD)
Video Support DCI 4K:
4K: 23.98, 24, 25, 29.97, 30, 50, 59.94, 60

UHD 4K:
2160p: 23.98, 24, 25, 29.97, 30, 50, 59.94, 60

HD:
1080p: 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
1080PsF: 23.98, 24, 25, 29.97, 30
1080i: 50, 59.94, 60
720p: 50, 59.94, 60

DVI:
2560 x 1600p: 50, 60
2560 x 1440p: 50, 60
1920 x 1440p: 50, 60
1920 x 1200p: 50, 60
1600 x 1200p: 50, 60
1440 x 1080p: 50 60
1440 x 900p: 50, 60
800 x 600p: 50, 60
640 x 480p: 60

SD:
525i: 59.94 NTSC
625i: 50 PAL
Audio Sample Rate 24-Bit, 48 kHz
Supported Codecs AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHR, DNxHD, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes LT, Apple ProRes 422 Proxy, Uncompressed 8-Bit 4:2:2, Uncompressed 10-Bit 4:2:2
Color Space Rec. 601, Rec. 709, Rec. 2020
Deep Color and HDR Supported
HDMI Video Sampling 8-, 10-, and 12-Bit RGB 4:4:4 (In All Modes up to 4K30)
8- and 10-Bit YUV 4:2:2 and 4:2:0 (In All Modes)
8-Bit RGB 4:4:4 (Supported in All DVI Modes)
HDMI Copy Protection Compliant
Power Consumption 23 W
Certifications FCC, CE, RCM, and KC
Operating Temperature 41 to 104°F / 5 to 40°C
Storage Temperature -4 to 113°F / -20 to 45°C
Relative Humidity (non-condensing) 0 to 90%
Length 4.3" / 10.9 cm
Weight 4.5 oz / 128 g
