Sennheiser SKP 500 G4 Pro Wireless Plug-On Transmitter

Item Code: SYN/SKP500G4-GBW

The Sennheiser SKP 500 G4 Plug-On Transmitter is a powerful plug-on transmitter that turns every wired dynamic or condenser microphone into a wireless transmitter for wireless G4 500 Series systems.

Note: GBw Block covers 606 to 678 MHz. Be sure to check the Sennheiser Frequency Finder for the best range to cover your needs!

RRP: 0   Save:

For purchasing information

What's In The Box?

  • SKP 500 G4 pro plug-on transmitter
  • POP 1 pouch with belt clip

The Sennheiser SKP 500 G4 Plug-On Transmitter is a powerful plug-on transmitter that turns every wired dynamic or condenser microphone into a wireless transmitter for wireless G4 500 Series systems. When paired with a dynamic microphone and portable receiver (sold separately) it provides pro-quality wireless performance. Power is supplied to the transmitter by two AA batteries.

Features

  • Professional sound and excellent construction quality
  • Easy to use and fast setup time
  • Easy and flexible wireless synchronisation between transmitter and receiver via infrared
  • Up to 88 MHz bandwidth, up to 32 channels
  • Range: up to 100 meters / 330 feet
  • Increased RF output power (10/30/50 mW)
  • Up to 8 hours of operation time
  • With 48 V phantom powering

Specifications

Frequency range GBw: 606 - 678 MHz
Dimensions Approx. 105 x 43 x 43 mm
Compander Sennheiser HDX
THD, total harmonic distortion ≤ 0.9 %
Weight (incl. batteries) approx. 195 g
Signal-to-noise ratio ≥ 120 dBA
RF output power switchable: Low: typ. 10 mW, Standard: typ. 30 mW, High: typ. 50 mW
Switching bandwidth up to 88 MHz
Peak deviation ±48 kHz
Nominal deviation ±24 kHz
Operating time Typically 8 h
Modulation Wideband FM
Power supply 2 AA batteries, 1.5 V or BA 2015 accupack
Current consumption at nominal voltage: typ. 210 mA with transmitter switched off: ≤ 25 μA
Input impedance 68 kΩ, unbalanced
Max. Input voltage 6 Veff
Powering 3 V battery / 2.4 V rechargeable battery
Transmission frequency Max. 3520 frequencies, adjustable in 25 kHz steps 20 frequency banks, each with up to 32 factory-preset channels, no intermodulation 6 frequency banks with up to 32 programmable channels
AF frequency response 80 – 18,000 Hz
Temperature Range -10 °C to +55 °C
