Sennheiser SKM 500 G4 Wireless Handheld Transmitter (GBw)

Code: SEN/507783
$470.00
Sennheiser SKM 500 G4 Wireless Handheld Transmitter is a powerful handheld transmitter with a lightweight aluminum housing. It's intended for use with the G4 series of wireless receivers and a microphone capsule (available separately). Note: GBw Block covers 606 to 678 MHz. Be sure to check the Sennheiser Frequency Finder for the best range to cover your needs!

ENQUIRE NOW

Got a question about this product?
Send us a message

Out of Stock

Out of stock - Usually ships in 3-5 days

What's In The Box?

  • SKM 500 G4 handheld transmitter
  • MZQ 1 microphone clamp
  • Sennheiser SKM 500 G4 Wireless Handheld Transmitter is a powerful handheld transmitter with a lightweight aluminum housing. It's intended for use with the G4 series of wireless receivers and a microphone capsule (available separately). The transmitter's menu-driven backlit LCD display shows the current frequency, frequency bank and channel number, metering of AF level, transmission status, muting function, battery status, and more. Two AA batteries power the transmitter.

    Features

    • Easy and flexible wireless synchronization between transmitter and receiver via infrared
    • Up to 32 compatible channels
    • Up to 88 MHz bandwidth with 3520 selectable frequencies, fully tunable in a stable UHF range
    • Ethernet connection for Wireless Systems Manager (WSM) control software for advanced frequency coordination in multi-channel setups
    • High RF output power (up to 50mW, adjustable in three steps 10/30/50) depending on country regulations
    • Requires an e 935, e 945, or e 965 microphone capsule (sold separately)

    Specifications

    Frequency range GBw: 606 - 678 MHz
    Dimensions Approx. Ø 50 x 265 mm
    Compander Sennheiser HDX
    THD, total harmonic distortion ≤ 0.9 %
    Weight (incl. batteries) approx. 450 g
    Signal-to-noise ratio ≥ 115 dBA
    RF output power switchable: Low: typ. 10 mW, Standard: typ. 30 mW, High: typ. 50 mW
    Switching bandwidth up to 88 MHz
    Peak deviation ±48 kHz
    Nominal deviation ±24 kHz
    Operating time Typically 8 h
    Modulation Wideband FM
    Power supply 2 AA batteries, 1.5 V or BA 2015 accupack
    Current consumption at nominal voltage: typ. 180 mA with transmitter switched off: ≤ 25 μA
    Powering 3 V battery / 2.4 V rechargeable battery
    Transmission frequency Max. 3520 frequencies, adjustable in 25 kHz steps, 20 frequency banks, each with up to 32 factory-preset channels, no intermodulation, 6 frequency banks with up to 32 programmable channels
    AF frequency response 80 – 18,000 Hz
    Temperature Range -10 °C to +55 °C
    Frequency stability ≤ ±15 ppm
