Angelbird AtomX SSD Mini

Angelbird AtomX SSDmini is Developed Exclusively for ATOMOS NINJA V 4K Workflows. Available in 500GB and 1TB Capacity

Product Options:



Got a question about this product?
Send us a message

The perfectly matched storage solution for your Atomos recorder

Angelbird’s AtomX SSDmini was custom made for the new ATOMOS NINJA V monitor recorder and is perfectly compatible with all the other available recorders. The AtomX SSDmini is 20 percent smaller than the average SSD (to fit the small footprint of the Ninja V), offers 500 GB and 1 TB of storage, has sustained read speeds of 550 MB/s and write speeds of 500 MB/s, captures CDNG up to 4K 30p, ProRes RAW HQ 5.7K up to 30p, plus 4K 60p and 2K 240p, sports a SATA III connector, and supports Stable Stream™ technology to never miss a frame.


  • SATA 6Gb/s, 3Gb/s & 1.5Gb/s Supported, SATA 3.0 Compliant
  • Up to 560MB/s Read & 520MB/s Write with Sustained 540MB/s Read & 500MB/s Write
  • Up To 4K60P / 2K240P Apple ProRes RAW & 4K30P CDNG
  • CNC-worked aluminium heatsink – Rock-solid build
  • Stable Stream™
  • X-ray. Magnetic. Shock. Temperature. PROOF.
  • ESD & Overload Protection. Adaptive Thermal Protection. Power Smoothing
  • Custom Designed for, and Authorised by, >ATOMOS
  • Register for 3-year Limited Warranty

Made to Last

Whether you are shooting in the desert or the snow-packed mountains, the AtomX SSDmini by Angelbird is your reliable partner. It’s tough, likes it rough, and is made to last.

Fits right in

We have made sure that the Atomos Master Caddy guide rail system guarantees perfect docking to the SATA port. And yes, you can even use the new AtomX SSDmini by Angelbird with the entire Atomos range of Ninja and Shogun devices, plus—with the use of an adaptor handle—even the Sumo19, Sumo19M and Shogun Studio. Now that comes in handy

Note: The Sumo 19, Sumo19M and Shogun Studio require the Atomos SSDmini Adaptor to be compatible.



Capacity 500GB, 1TB
Dimensions 80 x 75.5x 9.3 mm
Form factor SSDmini
Weight 90.0g

Technical Specifications

Interface SATA 6Gb/s and 1.5Gb/s
Supported SATA 3.0 Compliant
Over provisioning -0.09
Features Temperature Sensor, overload protection, TRIM, ECC, EMS Protection, built-in cache, SMART, NCQ

Performance Specifications

Sustained Read Speed up to 540MB/s
Sustained Write Speed up to 500 MB/s
Sequential Read Speed up to 560 MB/s
Sequenctial Write Speed up to 520 MB/s
Access Time (R/W) 65µs/40µs

Reliability Specifications

MTBF >2,400,000
Data Reliability Built-in EDC | ECC Function
Data Retention 10 years at 25°C
Endurance 500GB: 1500TBW,
1TB: 3,000TBW
Certifications RoHS, FCC and CE compliant, REACH

Electrical Specifications

DC Input Voltage 5V ±10%
Power Usage (idle | max) 500 GB: 0.35W |3.0W
1 TB: 0.35W |3.5W

Environmental Specifications

Shock Resistance (operating) 1000 G/0.5ms
Vibration resistance (operating) 2.17G RMS
Operating Temperature -20°C ~ +70°C
Storage Temperature -40°C ~ +85°C
Operating Humidity 5% to 95% non-condensing

Compatible With

Ninja V
Ninja Flame
Ninja Inferno
Sumo 19*
Sumo 19M*
Shogun Flame
Shogun Inferno
Shogun Studio*
*only with Atomos SSDmini Adaptor
