Dedo

Dedolight LED Lighting Kit -Bicolour

Item Code: DED/KLED2X1F-BI-S

The Dedolight LED Soft Lighting Kit offers a bicolour lighting solution with two bicolour DLED4.1 LED lights and one bicolour Felloni LED light panel in a portable package

RRP: 0   Save:

For purchasing information

An excellent portable lighting kit conveniently packaged into a Dedo transport case, this kit combines the optical quality and control from the award winning Dedo DLED4 fixture with the softer quality output of the Dedocolour Felloni LED Panel.

Kit Includes:

2 DLED4-BI Dedo focusing LED light head, bicolour

2 DT4-BI Power supply for DLED4 bicolour light heads

2 DPLS Light shield ring

2 DBD8 Barndoors

1 TP-DCOL-BI50HO Felloni LED panel, high output 50° bicolour

1 TP-LONI-SBX42 Felloni soft box

1 TP-LONI-SBXGRID40 Felloni textile grid for soft box, 40°

3 DST Dedo stands

1 DCHDKA2 Dedo hard transport case

DLED 4.1 BiColour Specifications

Light Source LED
Rating Not specified by manufacturer
Color Range 3200K - 5600 K
Focus Range 4.0 - 60°
Focus control: 1 complete turn
Mount Standard 5/8" Lighting spigot
Operating Position Any
Tilt Function Permanent friction
Photometrics At 5600K
At 3.0' (1.0 m) Footcandle/Lux
Flood: 109 / 1,170
Medium: 217 / 2,340
Spot: 655 / 7,050
At 9.0' (2.75 m)
Flood: 12 / 130
Medium: 24 / 260
Spot: 73 / 783
At 15' (4.5 m)
Flood: 4.3 / 47
Medium: 9.0 / 94
Spot: 26 / 282
At 3200K
At 3.0' (1.0 m) Footcandle/Lux
Flood: 71 / 760.5
Medium: 141 / 1,521
Spot: 425.7 / 4582.5
At 9.0' (2.75 m)
Flood: 7.8 / 84.5
Medium: 15.6 / 169
Spot: 47.5 / 509
At 15' (4.5 m)
Flood: 2.8 / 30.5
Medium: 5.8 / 61
Spot: 17 / 183
Operating Voltage 100 - 260 VAC 50/60 Hz via separate DT4.0-1BI or DT4.0-1BI-DMX
10.2 - 18 VDC via DT4.0-1BI-BAT power supply
Power Consumption 47 W (via optional) AC power supply
Dimming Yes, 100 - 20%
Safety Protection Class III, SELV
No UV radiation
Cooling Passive (no fan)
Weight 1.36 kg (3.0lb)

Dimensions

Felloni2 BiColour 50° High Output Specifications

Beam Angle 50° Flood Angle
Light Source 576 LEDs
Colour Range 3200 - 5600K
Photometrics: 838 Lux @ 2 Metres
CRI Ra 87
Operating Voltage AC: 100 - 240V AC, 50 / 60 Hz
DC: 10 - 16.8V AC
Power Consumption 47.2w
Dimming 100 - 0%
Mount 5/8" (16 mm)
Dimensions Head only: 12 x 12 x 3" (30.4 x 30.4 x 7.6 cm)
Head with yoke: 15 x 13.9 x 3" (38 x 35.2 x 7.6 cm)
Weight 4.4 lb (2.0 kg)
With all accessories: 5.5 lb (2.5 kg)
