Zeiss Supreme Prime Lenses

Code:

The ZEISS Supreme Prime lenses are designed for cinematic large-format sensor coverage, making them the ideal choice for current and future camera systems. At T1.5 the ZEISS Supreme Primes demonstrate their unsurpassed craftsmanship in tricky low-light environments.

For purchasing information

Enquire Now

Overview
Specifications

Opening up new dimensions - ZEISS Supreme Prime Lenses

Consistency is one of the key elements offered by the ZEISS Supreme Prime lenses: that means consistent coverage, color rendering, aperture, size, weight and ergonomics. All the lenses across the family cover full frame and even bigger sensors with an image circle of 46.2 mm. The Supreme Prime lenses are color matched across the full range and most feature a fast T-stop of T1.5.

The small front diameter of 95 mm on almost all lenses and standardized positioning of the focus and iris rings across the whole family facilitate fast and easy equipment changeout. The compact and lightweight design means you enjoy easy and comfortable handling. The ultra-smooth focus rotation of the Supreme Prime lenses even in extreme temperatures allows for small motors to make sure you have an easy setup that’s enjoyable to work with.

ZEISS Supreme Prime Lenses - Reel from ZEISS Cinematography on Vimeo.

Cinematic large-format coverage and high speed

Aesthetic focus fall-off and elegant bokeh

A very smooth transition between in-focus and out of focus areas characterize the unique look of the ZEISS Supreme Prime lenses. This adds richer texture and greater depth to the image.

A versatile look and gentle sharpness

The ZEISS Supreme Primes possess a look, which ensures freedom in creating the look you want to achieve. Especially when capturing crucial textures such as skin tones, the unique quality of the ZEISS Supreme Prime lenses is a gentle sharpness that renders a crisp but organic look.

Efficiency and reliability throughout the entire production

The unique ZEISS eXtended Data technology offers lens metadata critical for VFX-intensive productions and workflows on set. The frame accurate information about focal length, focusing distance, T-stop and depth-of-field enables the camera assistant to work more precisely and eliminates guesswork for the DIT. The ZEISS specific distortion and vignetting data makes shooting grids redundant and accelerates compositing and stitching in post-production.

Made in Germany, used and maintained around the globe

ZEISS Cinematography lenses are designed and manufactured at ZEISS headquarters in Oberkochen, Germany. The lenses are assembled manually and engraved with individually calibrated scales. Serviceability is a top priority starting in the initial stages of the development process. ZEISS has built up a global service network in the recent years with authorized service stations offering service according to factory standards in the US, Europe and Asia.

Specifications

	Release	Aperture	Close Focus1	Length²	Front diameter	Weight	Horizontal Angle of View
							Full-frame³	Super 35⁴
Supreme Prime 15 mm T1.8	2021	T1.8 to T22	tbd	tbd	114 mm \| 4.5‘‘	tbd	tbd	tbd
Supreme Prime 18 mm T1.5	09/2020	T1.5 to T22	0.35 m \| 14‘‘	163 mm \| 6.4‘‘	114 mm \| 4.5‘‘	2.27 kg \| 5.00 lbs	88.4°	67.9°
Supreme Prime 21 mm T1.5	Shipping	T1.5 to T22	0.35 m \| 14‘‘	120 mm \| 4.7‘‘	95 mm \| 3.7‘‘	1.61 kg \| 3.54 lbs	79.5°	59.8°
Supreme Prime 25 mm T1.5	Shipping	T1.5 to T22	0.26 m \| 10‘‘	119 mm \| 4.7‘‘	95 mm \| 3.7‘‘	1.42 kg \| 3.13 lbs	70.8°	52.3°
Supreme Prime 29 mm T1.5	Shipping	T1.5 to T22	0.33 m \| 13‘‘	121 mm \| 4.8‘‘	95 mm \| 3.7‘‘	1.61 kg \| 3.55 lbs	64°	46.8°
Supreme Prime 35 mm T1.5	Shipping	T1.5 to T22	0.32 m \| 13‘‘	119 mm \| 4.7‘‘	95 mm \| 3.7‘‘	1.40 kg \| 3.09 lbs	55°	39.6°
Supreme Prime 40 mm T1.5	09/2020	T1.5 to T22	0.40 m \| 16‘‘	119 mm \| 4.7‘‘	95 mm \| 3.7‘‘	1.49 kg \| 3.28 lbs	47.4°	33.8°
Supreme Prime 50 mm T1.5	Shipping	T1.5 to T22	0.45 m \| 18‘‘	119 mm \| 4.7‘‘	95 mm \| 3.7‘‘	1.22 kg \| 2.69 lbs	39°	27.5°
Supreme Prime 65 mm T1.5	Shipping	T1.5 to T22	0.60 m \| 2‘	121 mm \| 4.8‘‘	95 mm \| 3.7‘‘	1.63 kg \| 3.59 lbs	30.5°	21.3°
Supreme Prime 85 mm T1.5	Shipping	T1.5 to T22	0.84 m \| 2‘9‘‘	119 mm \| 4.7‘‘	95 mm \| 3.7‘‘	1.42 kg \| 3.13 lbs	24°	16.7°
Supreme Prime 100 mm T1.5	Shipping	T1.5 to T22	1.10 m \| 3‘9‘‘	119 mm \| 4.7‘‘	95 mm \| 3.7‘‘	1.70 kg \| 3.74 lbs	20.4°	14.2°
Supreme Prime 135 mm T1.5	Shipping	T1.5 to T22	1.35 m \| 4‘5‘‘	146 mm \| 5.7’’	114 mm \| 4.5‘‘	2.27 kg \| 5.00 lbs	15.6°	10.9°
Supreme Prime 150 mm T1.8	Shipping	T1.8 to T22	1.50 m \| 4‘11‘‘	146 mm \| 5.7’’	114 mm \| 4.5‘‘	2.27 kg \| 5.00 lbs	13.7°	9.5°
Supreme Prime 200 mm T2.2	09/2020	T2.2 to T22	2.00 m \| 6‘7‘‘	183 mm \| 7.2’’	114 mm \| 4.5‘‘	2.87 kg \| 6.33 lbs	10.3°	7.1°

1 Close focus distance is measured from the image plane
2 Front to PL mount flange
3 The specified weight refers to the ZEISS CP.3 standard lenses. The ZEISS CP.3 XD lenses weigh about 0.01 kg / 0.02 lbs more.
4 Horizontal angle of view for a full-frame camera (aspect ratio 1:1.5, dimensions 36 mm x 24 mm / 1.42“ x 0.94“)
5 Horizontal angle of view for an ANSI Super 35 Silent camera (aspect ratio 1:1.33, dimensions 24.9 mm x 18.7 mm / 0.98“ x 0.74“)
