SWIT Hot Swap Plate for Pocket Batteries

Code: SWI/KA-M20S
KA-M20S is an extender plate for SWIT Pocket V-mount Batteries

For purchasing information

Enquire Now

Pocket V-mount Batteries Extender

Hot swap application

KA-M20S is an extender plate for SWIT Pocket V-mount Batteries. Installed with 2x PB-M series batteries, the size is equivalent to a standard large capacity V-mount battery, and the KA-M20S plate can draw the 2 batteries one-by-one as hot swap mode, or use together as high load mode.

Two Power Modes

Hot Swap mode and High Load mode

When the device power consumption is less than single PB-M battery Max load (PB-M98S 100W load), the KA-M20S would be “Hot Swap mode” – 2 batteries one-by-one using, and the free battery can be changed any time. When the device power consumption is more than single PB-M battery Max load (PB-M98S 100W load), the KA-M20S would be “High Load mode” – 2 batteries using together, and none of the batteries can be removed. The Hot Swap mode and High Load mode can be automatically switched according to current power consumption of the device.

Power/Hot Swap Indicators

There’re independent power indicators for both batteries. The flashing of top power LED indicates this battery is discharging. And the flashing of EMPTY LED means this battery is empty and need to change in time.

2 D-tap Power Output

There’re 2 D-tap sockets on the top side and right side of the KA-M20S plate, for flexible connection to various cameras.

Specifications

Input SWIT PB-M series Pocket V-mount Batteries x2
Output V-mount 11-16.8V
D-tap x2, 11-16.8V
Max Load Hot swap mode V-mount: Max load of the single smaller battery
D-tap: Max load of the single smaller battery and limited 150W/10A
High load mode V-mount: Max load of the single smaller battery x2
D-tap: Max load of the single smaller battery x2 and limited 150W/10A
Working temperature -20°C ~ 50°C
Dimension 148×108×28mm
Net weight 238g
