Sony VENICE CineAlta Camera

Code:
Sony proudly introduces its next generation motion picture camera system with forward thinking full frame sensor, phenomenal colour science and user-friendly operation.

For purchasing information

Enquire Now

36x24mm Full-Frame Sensor for Cinema

VENICE is equipped with a 36x24mm full-frame image sensor, designed specifically for the demands and performance of high end cinematography, and can capture images up to a maximum resolution of 6048 x 4032*. By switching imager modes, VENICE can natively support Super35 24.9x18.7mm, 4096 x 3024 resolution (equivalent to 4-perforation motion picture film) and Super35 24.9x14.0mm 4096 x 2160 resolution (equivalent to 3-perforation motion picture film). In other words, VENICE’s new full-frame sensor can capture in almost any format, including full 18mm-height Super35 Anamorphic and spherical and full-frame 24mm-height Anamorphic and spherical*. Almost any aspect ratio can be conjured up: 1.85:1, 2.39:1, 17:9, the list goes on in full-frame* or Super35.

With VENICE, Sony is giving users the option to customize their camera by only enabling the features needed, according to their individual production requirements. Licenses will be available to expand the camera’s capabilities with new features including 4K anamorphic and full-frame*.

Creative Freedom

Full-Frame Full width 36 mm 6K*

In full-frame, you can use the full 6048 pixel width of the sensor for widescreen spherical 2.39:1 or Large Format Scope. Full-Frame can be used creatively in a number of ways – for example, to allow for extra shallow depth of field or super-wide shooting.

Super35 full height 2x squeeze Anamorphic

For anamorphic shooting and production, Super35 full height 2x squeeze anamorphic is supported.

Super35 17:9 and 16:9

These popular imager sizes are natively supported by VENICE. Current Super35mm PL mount lenses can be used.

Fast Shutter

Jello effect is something that we don’t need when filming. VENICE has high speed readout sensor which minimizes the jello effect that are typical in the CMOS sensor

Phenomenal latitude

VENICE has an exceptional 15+ stops of latitude, with low noise for extraordinary performance in delivering phenomenal images in conditions from searing sunlight to almost no light. VENICE's real-world performance also excels at High Dynamic Range imaging and allows unprecedented creative freedom in grading.

More colors for More Expression

VENICE can exceed Rec. 2020 color space. This means the color range is wider than DCI-P3 and can beautifully reproduce the true color of the scene in front of your lens. This also provides the broad palette in the grading suite using the established workflow of Sony’s third generation LOG gamma encoding (S-Log3), and Ultra-wide color space.

Engineered to Survive

VENICE’s chassis is engineered to be amazingly robust and has been rigorously tested in the harshest conditions. Its ventilation system is completely isolated from all electronic components to prevent ingress of dust, sand and splash. The silent-running fan can be cleaned or even swapped out on set quickly and easily.

Depth of Field

As the sensor size gets larger, depth of field becomes shallower. VENICE’s wide 36 mm full-frame sensor can capture images that have the equivalent of 1-2 stops shallower depth of field compared to Super35.*

6K High Resolution*

The stunning full 6K resolution of the camera can be recorded directly in X-OCN (16 bit Extended tonal range Original Camera Negative) file format. Also, XAVC 4K can be captured onto SxS cards while still sampling from the full 6K resolution of the sensor.

World’s first 8-step Mechanical ND Filter

VENICE is the world’s first camera of its class with a servo-controlled 8-step Mechanical ND filter mechanism built into the camera chassis. It offers a massive ND of 0.3 (1/2 = 1 stop) to ND2.4 (1/256 = 8 stops) range that reduces time lost on set changing external filters. The ND filters also greatly increase VENICE’s flexibility when being controlled remotely on drones and cranes, or in an underwater housing.

Anamorphic Look

VENICE’s support for anamorphic lenses combined with its ability to shoot 4:3 aspect ratio at a horizontal resolution of 4K allows the capture of breathtakingly beautiful images with stunning lens flare, bokeh and emotional impact.

* Firmware update required

Model Name

Model Name MPC-3610

General

Power Requirements DC12V (11~17.0V)
DC24V (22~32.0V)
Operating Temperature 0 ~ 40℃
Storage Temperature -20℃〜60℃
Mass Approx. 3.9kg (8lb 10oz) (without lens, handle, VF attachment expansion bottom plate and accessories)
Dimensions 133 x 159 x 172 mm (without protrusion)

Camera

Imaging Device Full-Frame CMOS
Imaging Device Pixel Count 24.7M (total), 24.4M (effective)
Imaging Device Size 36.2x24.1mm. 43.5mm (diagonal).
Built-In ND Filters Clear, 0.3(1/2), 0.6(1/4), 0.9(1/8), 1.2(1/16), 1.5(1/32), 1.8(1/64), 2.1(1/128), 2.4(1/256)
ISO Sensitivity ISO500
Lens Mount PL Mount
E-mount (lever lock type, without supplied PL lens mount adaptor)
Latitude 15+ Stop
Select FPS* Imager mode:
3.8K 16:9, 4K 17.9: 1-60FPS
4K 4:3: 1-48FPS
4K 6:5, 5.7K 16:9, 6K 17:9, 6K 1.85:1, 6K 2.39:1: 1-30FPS
6K 3:2: 1-24FPS
White Balance 2000~15000Kelvin and Green/Magenta adjust, AWB*
Gamma Curve S-Log3

Recording

Recording Format (Video) XAVC 4K Class480: 23.98p, 24p, 25p, 29.97p
XAVC 4K Class300: 23.98p, 24p, 25p, 29.97p, 50p, 59.94p
XAVC QFHD Class480: 23.98p, 25p, 29.97p
XAVC QFHD Class300: 23.98p, 25p, 29.97p, 50p, 59.94p
MPEG HD422(1920x1080): 23.98p, 24p, 25p, 29.97p, 50i, 59.94i
HD ProRes 422HQ*: 23.98p, 24p, 25p, 29.97p, 50p, 59.94p, 50i, 60i
HD ProRes 422*: 23.98p, 24p, 25p, 29.97p, 50p, 59.94p, 50i, 59.94i
HD ProRes 422 Proxy*: 23.98p, 24p, 25p, 29.97p, 50p, 59.94p, 50i, 59.94i
Recording Format (RAW/X-OCN) *required AXS-R7 RAW SQ:
4K 17:9 (4096 x 2160): 23.98p, 24p, 25p, 29.97p, 50p, 59.94p
3.8K 16:9 (3840 x 2160): 23.98p, 25p, 29.97p, 50p, 59.94p
X-OCN ST/LT:
6K 3:2(6048 x 4032)*: 23.98p, 24p,
6K 2.39:1 (6048 x 2530)*: 23.98p, 24p, 25p, 29.97p
6K 1.85:1 (6048 x 3270)*: 23.98p, 24p, 25p, 29.97p
6K 17:9 (6048 x 3190)*: 23.98p, 24p, 25p, 29.97p
5.7K 16:9 (5672 x 3190)*: 23.98p, 25p, 29.97p
4K 6:5(4096x3432)*:23.98p, 24p, 25p, 29.97p
4K 4:3(4096x3024) :23.98p, 24p, 25p*, 29.97p*
4K 17:9 (4096 x 2160): 23.98p, 24p, 25p, 29.97p, 50p, 59.94p
3.8K 16:9 (3840 x 2160): 23.98p, 24p, 25p, 29.97p, 50p, 59.94p
Recording Format (Audio) LPCM 4ch , 24-bit 48-kHz

Inputs/Outputs

DC Input XLR-type 4pin (male)
Battery DC Input Square-shaped 5pin connector
DC Output 12V: Hirose 4pin x1
24V: Fischer 3pin x2
SDI Output BNC×4, (12G, 3G, 1.5G-SDI)
HD MONI Output BNCx1 (1.5G-SDI)
HDMI Output Type A ×1
VF LEMO 26pin
Audio Input XLR-type 5pin (female) x1 (LINE/ AES/EBU / MIC / MIC+48V selectable)
Timecode Input BNC x1
Genlock Input BNC x1
AUX LEMO 5pin (female) x1 (Timecode Output)
Remote* 8pin x1
Lens* 12pin x1
Lens Mount Hot Shoe 4pin x2, conforming to Cooke /i Intelligent Electronic Lens System
Network* RJ-45 type x1, 10BASE-T, 100BASE-TX
USB* USB host, type-A x1
Headphone Output Stereo mini jack x1
Speaker Output Monaural
Media type ExpressCard/34 slot×2
SD card slot ×1
* Firmware update required
