Preston

Preston MDR-4, 2 channel motor driver

Item Code: PRE/4150

The MDR-4 takes all the best features from the MDR-3 and packs them into a sleek, compact package. It accepts commands from Preston Hand Units connected via the rugged G4 wireless link and controls up to two digital motors and camera run/stop functions for film and video cameras.

RRP: 0   Save:

  • Qty:
  • Price:
    $7,960.00
    inc. GST

Found this item cheaper elsewhere? Let us know

The MDR-4 takes all the best features from the MDR-3 and packs them into a sleek, compact package. It accepts commands from Preston Hand Units connected via the rugged G4 wireless link and controls up to two digital motors and camera run/stop functions for film and video cameras. The MDR-4 automatically finds the span of the lens once each motor is plugged in, and each channel has its own three-level torque adjustment and direction switch to drive virtually any lens.

The Analog port lets you plug a Micro Force or broadcast-style control directly into the MDR-4, controlling the motor of your choice as configured in the HU3 Mode menu.

The Serial port connects to the Light Ranger 2, transmitting distance information wirelessly to the HU3 and Video Interface unit. Firmware updates can be loaded through the Serial port or the mini USB port.

This unit comes with:

  • On-The-Go (OTG) Mini USB adapter cable

Specifications


Dimensions2.9in x 4.1in x 1.6in
DisplayWireless Channel
Frequency Band2.4 GHz
Input Voltage12-36VDC
Maximum Current Draw2A (at 24VDC)
Motor ChannelsUp to two
Number of Wireless Channels60
Operating Temperature0F to 122F
Weight10.6oz (300g)
Wireless Channels60
Wireless Range300m (line of sight)
