AJA Up/Down/Cross Converter

Code: BLO/AJA-UDC
The UDC is a broadcast quality Up/Down/Cross Mini-Converter which can convert between SD, HD, and 3G video formats. Using the same AJA industry leading conversion technology as in our model FS2, the UDC provides very high quality conversions at a low price. I/Os include SD/HD/3G SDI Input and Output, HDMI output, and 2-channel RCA style audio output.

For purchasing information

Enquire Now

The UDC is a broadcast quality Up/Down/Cross Mini-Converter which can convert between SD, HD, and 3G video formats. Using the same AJA industry leading conversion technology as in our model FS2, the UDC provides very high quality conversions at a low price. I/Os include SD/HD/3G SDI Input and Output, HDMI output, and 2-channel RCA style audio output. The UDC can be controlled by local dipswitches with additional control available via USB and AJA's MiniConfig application. A Reference Input allows the UDC to be locked to a local reference.

Compact and Portable

AJA Mini-Converters are small enough to fit behind a monitor, in the back of a rack or directly on a camera rig. A locking power connector can't accidentally pull loose and an optional P-TAP power cable allows for battery power in remote locations.

AJA Quality - Guaranteed

All AJA Mini-Converters are covered by a five year warranty and AJA's advanced replacement policy. If a replacement is necessary, AJA will ship a new unit immediately without the need to send the original unit back first, ensuring you are up and running again as quickly as possible.

Features

  • Converts between SD, HD, and 3G HD formats
  • Supports 1080p50/60
  • Very high quality conversions
  • 16-channel embedded SDI audio input
  • 16-channel embedded SDI audio output
  • 8-channel HDMI audio output
  • 2 RCA-style analog outputs at -10dBV (nominal)
  • Reference Input
  • Configure via Dipswitch or USB port and supplied MiniConfig software
  • Uses 5-20V power supply, included
  • five year warranty

AJA Mini-Matrix

Information on the complete line of AJA Mini-Converters is now available as a mobile app on iOS. The Mini-Converter product line is extensive and this app helps you find the right converter for any situation, wherever you are.

Individual products have links back to the main AJA website for more details and you can email product information directly from the app. The free AJA Mini-Matrix app for iPad® and iPhone® is available now in the Apple iTunes® Store.

Specifications

SDI Input & Output 1 x SD/HD/3G-SDI input (auto-selected), SMPTE-292/296/424 (BNC connector)
1 x SD/HD/3G-SDI output, SMPTE-292/296/424 (BNC connector)
Formats 525i59.94, 625i50
1080i 50/59.94
720p 23.98/24/25/29.97/30/50/59.94/60
1080p 23.98/24/25/29.97/30/59.94/60
1080psf 23.98/24/25/29.97/30
Reference Input Color Black
Tri-Level sync
HDMI Output 10-bit HDMI v1.4a
Audio I/O 16-channel embedded SDI audio input
16-channel embedded SDI audio output
8-channel HDMI audio output
2 RCA-style analog outputs at -10dBV (nominal)
HDCP The UDC does not encode the HDMI output with HDCP encryption. By definition, HD-SDI inputs to the UDC are unencrypted. The HDMI specification requires HDMI monitors to support unencrypted inputs
User Controls USB port used with supplied cable and MiniConfig software application to configure device via PC/Mac
Power 5 VDC regulated, 3 W
Dimensions 5.8 x 3.1 x 1" (147 x 79 x 25 mm)
