VIDEO |
Video Input |
1x HDMI Type A receptacle |
Video Output |
1x HDMI Type A receptacle |
Supported Resolutions |
1080p 23.98/24/25/29.97/30/50/59.94/60
720p 50/59.94/60 |
Video Compression |
H.264 (AVC), Main profile |
Supported Video Bitrate |
250 kbps to 15 Mbps |
Preset Bitrates/Resolutions |
Max: 12 Mbps + 256 kbps audio 1920x1080
HD+: 8 Mbps + 256 kbps audio 1920x1080
HD: 5 Mbps + 192 kbps 1920x1080
High: 3 Mbps + 192 kbps 1280x720
Medium: 1.5 Mbps + 128 kbps 960x540
Low: 800 kbps + 128 kbps 736x414
Mobile: 500 kbps + 96 kbps 480x270
|
Video Format Conversion |
Support Built-in video scaler |
AUDIO |
Audio Inputs |
Embedded HDMI audio input, 2-Channel
Analog line-in or mic-in, 2-Channel |
Audio Compression |
AAC-LC |
Supported Audio Bitrate Details |
HD: 256 kbps
High: 192 kbps
Medium: 128 kbps
Low: 96 kbps
Mobile: 48 kbps |
PHYSICAL ATTRIBUTES |
Dimensions |
4.1” W x 2.9” D x 1.1” H (105 x 75 x 28 mm) |
Weight |
5.6oz [160g] |
Construction |
Machined aluminum and ABS Plastic |
Mountability |
1x ¼-20 plus 2 x M3 on the bottom plate |
NETWORK |
Ethernet |
10/100/1000 BASE-T |
Wireless |
WiFi: Dual Band MIMO 802.11 ac/a/b/g/n
Internal Antennas: Internal 0dBi antennas |
USB |
USB type A (host) for 3G/4G modem support |
WiFi Channel Selection |
Auto with 3 modes: 2.4 or 5 GHz, Auto (2.4 GHz only), Auto (5 GHz only)
Manual: Configurable to specific channels |
Bonding |
Simultaneous bonding over up to 3 networks: Ethernet, Wi-Fi, USB cellular modem |
Cloud Services |
Sharelink |
Network Protocols |
TCP/IP, UDP, HTTP, DHCP, NTP, SSL, IGMP |
Video Transport Protocols |
RTMP, RTMPS, AirMix, Sharelink bonding, RTSP |
Integrated Platforms Custom |
RTMP/S, YouTube Live, Facebook, Vimeo Livestream, and AirMix |
INTERFACES |
Configuration |
Interface OLED display with navigation joystick, Feature-rich Web UI for configuration
and control |
Switches |
Go Live and reset switch |
Recording/Storage |
Full size SD/SDXC (class 6 and above) formatted exFAT, USB formatted exFAT |
Mobile App |
VidiU App for iOS or Android devices |
USB Interface Functionality |
Powered USB 2.0 host port |
POWER |
Power Input |
USB-C host port (5-15V) |
Nominal Power Consumption |
Ethernet: 4.5W
WiFi: 6W
USB Modem: 7W |
