Dedolight LED Lighting Kit -Bicolour
The Dedolight LED Soft Lighting Kit offers a bicolour lighting solution with two bicolour DLED4.1 LED lights and one bicolour Felloni LED light panel in a portable package
DED/KLED2X1F-BI-S
False
Dedolight
1074
False
1
0
False
0
1
0
https://www.lemac.com.au/site/DefaultSite/filesystem/images/dedo/dedo_KLED2X1F.jpg
Lighting
Lighting
Lighting Kits
FAST SHIPPING
Products in stock are generally shipped the same day.
Dedolight LED Lighting Kit -Bicolour
Code: DED/KLED2X1F-BI-S
The Dedolight LED Soft Lighting Kit offers a bicolour lighting solution with two bicolour DLED4.1 LED lights and one bicolour Felloni LED light panel in a portable package
For purchasing information
Enquire Now
An excellent portable lighting kit conveniently packaged into a Dedo transport case, this kit combines the optical quality and control from the award winning Dedo DLED4 fixture with the softer quality output of the Dedocolour Felloni LED Panel.
Kit Includes:
2 DLED4-BI Dedo focusing LED light head, bicolour
2 DT4-BI Power supply for DLED4 bicolour light heads
2 DPLS Light shield ring
2 DBD8 Barndoors
1 TP-DCOL-BI50HO Felloni LED panel, high output 50° bicolour
1 TP-LONI-SBX42 Felloni soft box
1 TP-LONI-SBXGRID40 Felloni textile grid for soft box, 40°
3 DST Dedo stands
1 DCHDKA2 Dedo hard transport case
DLED 4.1 BiColour Specifications
|
Light Source
|
LED
|
|
Rating
|
Not specified by manufacturer
|
|
Color Range
|
3200K - 5600 K
|
|
Focus Range
|
4.0 - 60°
Focus control: 1 complete turn
|
|
Mount
|
Standard 5/8" Lighting spigot
|
|
Operating Position
|
Any
|
|
Tilt Function
|
Permanent friction
|
|
Photometrics
|
At 5600K
At 3.0' (1.0 m) Footcandle/Lux
Flood: 109 / 1,170
Medium: 217 / 2,340
Spot: 655 / 7,050
At 9.0' (2.75 m)
Flood: 12 / 130
Medium: 24 / 260
Spot: 73 / 783
At 15' (4.5 m)
Flood: 4.3 / 47
Medium: 9.0 / 94
Spot: 26 / 282
At 3200K
At 3.0' (1.0 m) Footcandle/Lux
Flood: 71 / 760.5
Medium: 141 / 1,521
Spot: 425.7 / 4582.5
At 9.0' (2.75 m)
Flood: 7.8 / 84.5
Medium: 15.6 / 169
Spot: 47.5 / 509
At 15' (4.5 m)
Flood: 2.8 / 30.5
Medium: 5.8 / 61
Spot: 17 / 183
|
|
Operating Voltage
|
100 - 260 VAC 50/60 Hz via separate DT4.0-1BI or DT4.0-1BI-DMX
10.2 - 18 VDC via DT4.0-1BI-BAT power supply
|
|
Power Consumption
|
47 W (via optional) AC power supply
|
|
Dimming
|
Yes, 100 - 20%
|
|
Safety
|
Protection Class III, SELV
No UV radiation
|
|
Cooling
|
Passive (no fan)
|
|
Weight
|
1.36 kg (3.0lb)
|
Dimensions
Felloni2 BiColour 50° High Output Specifications
| Beam Angle |
50° Flood Angle |
| Light Source |
576 LEDs |
| Colour Range |
3200 - 5600K |
| Photometrics: |
838 Lux @ 2 Metres |
| CRI Ra |
87 |
| Operating Voltage |
AC: 100 - 240V AC, 50 / 60 Hz
DC: 10 - 16.8V AC |
| Power Consumption |
47.2w |
| Dimming |
100 - 0% |
| Mount |
5/8" (16 mm) |
| Dimensions |
Head only: 12 x 12 x 3" (30.4 x 30.4 x 7.6 cm)
Head with yoke: 15 x 13.9 x 3" (38 x 35.2 x 7.6 cm) |
| Weight |
4.4 lb (2.0 kg)
With all accessories: 5.5 lb (2.5 kg) |
