TILTA

Tilta Camera Cage for Panasonic Varicam 35

Item Code: TIL/ES-T75

Arm your camera with this Tilta camera cage specifically designed for the Panasonic Varicam 35. It provides a high quality aluminum, CNC-milled protective armor for your camera that has several ¼”-20 and ⅜”-16 mounting points for attaching accessories.

RRP: 0   Save:

  • Qty:
  • Price:
    $2,750.00
    inc. GST

Found this item cheaper elsewhere? Let us know

Rod System
select

What's In The Box?

  • 1x Front top handle
  • 1x Back top handle
  • 1x 15mm LWS top rod adapter
  • 1x Front top plate
  • 1x Back top plate
  • 1x Right side plate
  • 1x Power supply voltage readout screen
  • 1x Front plate
  • 1x EVF bracket
  • 1x Original Panasonic EVF bracket adapter
  • 1x Panasonic Varicam 35 battery plate

Arm your camera with this Tilta camera cage specifically designed for the Panasonic Varicam 35. It provides a high quality aluminum, CNC-milled protective armor for your camera that has several ¼”-20 and ⅜”-16 mounting points for attaching accessories.

The Tilta Battery Plate for Panasonic Varicam 35 (available in either gold mount or V-mount) integrates with the camera body to provide several power outputs. Pins on the plate directly communicate with the top plate when attached which transfers power output functionality. This allows you to power multiple accessories throughout the cage.

The top plate offers 15mm LWS rod support on the back side of the camera while the top handle offers rod support off the front of the camera, allowing you to mount rod-based accessories in a variety of ways. The front rod bracket on the top handle allows you to comfortably attach your Sony Varicam 35 EVF.

The side plate of the cage gives you extra ¼”-20 and ⅜”-16 mounting points as well as camera armor while also allowing you to mount the included power supply voltage readout screen. This screen allows you to easily distinguish what amount of power your camera battery has.

On the bottom of the cage is a 15mm LWS baseplate that allows you to attach various accessories via 15mm rods. The plate can mount to a Tilta Standard Lightweight Dovetail Plate to allow you to easily slide on and off of an operating setup. It also includes an ergonomic shoulder pad on the bottom so that you can quickly and easily detach from the dovetail plate and be shoulder mount-ready in no time. The plate also has Arri Standard Rosette connections on the left and right sides to allow you to attach handles for handheld operation.

Specifications

Compatibility Panasonic VariCam 35 Camera
Material Anodized CNC aluminum
Inputs and Outputs Rear Top Plate:
3 x 14.8 V 3-pin Fischer outputs
2 x 14.8 V 2-pin LEMO-style outputs

Battery Plate and Power Distribution Unit:
2 x 14.8 V 3-pin Fischer outputs
2 x 14.8 V 2-pin LEMO-style outputs
1 x 12-14.8 V 6-pin LEMO-style input
Power Output 3 A max. (each output)
