Panasonic Lumix DC-GH5S (Body Only)

PANASONIC

Step up to the professional grade Panasonic LUMIX GH5s C4K mirrorless camera, featuring high performance, durability, mobility, and low light gathering needed for professional Cinematic and Anamorphic 4K video production. The LUMIX GH5s supports important recording features like 14bit RAW for stills, dual native IS0, Panasonic XLR mic Adaptor support, and the return of multi-aspect capture. THe GH5S comes pre-installed with HDR Hybrid Log Gamma and Panasonic’s V-LogL
  • Qty:
  • Price:
    $3,340.00
    inc. GST

Step up to the professional grade Panasonic LUMIX GH5s C4K mirrorless camera that offers over 29 LUMIX and LEICA compact lens options built on the next-generation (ILC) interchangeable lens camera standard [Micro Four Thirds] pioneered by Panasonic. Its “mirrorless” design enables the high performance, durability, mobility, and low light gathering needed for professional Cinematic and Anamorphic 4K video production. The LUMIX GH5s includes cutting-edge C4K: 60p50p 4:2:0 8-bit, 30p25p24p 4:2:2 10-bit, 4K: 60p50p 4:2:0 8-bit, 30p25p24p 4:2:2 10-bit recording* with unlimited recording. The GH5s comes pre-installed with HDR Hybrid Log Gamma and Panasonic’s V-LogL along with professional grade exposure tools like: Time Code sync, Waveform, Vector Scopes, and programmable Zebra patters. The LUMIX GH5s supports important recording features like 14bit RAW for stills, dual native IS0, Panasonic XLR mic Adaptor support, and the return of multi-aspect capture.

4:2:2 10-bit Internal Recording

The LUMIX GH5s is capable of internal SD card capture of 4:2:2 10-bit C4K/4K video recording without the banding so prone to 8-bit. Plus simultaneously feed 4:2:2 10-bit real-time image output through its full-size HDMI port (Type A) to an external monitor or recorder*. It is suitable for professional video making that requires accurate monitoring of the imagery or high quality recording to external codec devices (such as ProRes). 400Mbps (ALL-Intra) high bitrate recording mode is also available.

A cable lock holder for the HDMI cable is bundled with the LUMIX GH5s to prevent cable disconnection problems. * C4K/4K 4:2:2 10-bit 60p/50p video is output only.

The Highest Video Quality in LUMIX History

Welcome to a new generation of LUMIX GH video performance. Designed exclusively for the LUMIX GH5S, the new Digital Live MOS sensor offers 10.28 effective megapixels and a significantly higher photoreceptive surface per pixel, delivering an ultra-wide dynamic range.

Dual Native ISO, a technology found in broadcast video cameras, enables the use of 400 & 2,500 ISO as base points to raise the highest normal ISO setting of 51,200, and an extension to 204,800 ISO. This technology provides ultra-sensitive video capture with impressively low noise.

Exceptional low-light performance is a key capacity for professional videography, and you’ll enjoy this and much more with the new LUMIX GH5s!

Features

Multiple Aspect Ratios — A LUMIX GH5S Exclusive!

The LUMIX GH5s sensor is capable of multiple aspect ratios; 4:3, 17:9, 16:9 and 3:2. Thanks to broad margins of effective pixels, focal length does not change in these aspect ratios. Available for still photography, 4K and C4K video, and in Anamorphic mode, this function allows you to fully leverage the angle of view of the lens for more creative options.

Also, even while using a larger sensor, high readout speeds are achieved. Rolling shutter distortion, compared to the LUMIX GH5, is suppressed by approximately 1.3x with high readout speeds when recording video or using an electronic shutter.

Anamorphic Video Mode

Ideal for recording with 'squeezed' cinematic filmmaking lenses. In anamorphic desqueeze display mode, images are displayed in a cinemascope aspect ratio.

Wave Form Monitor & Vectorscope

To check brightness, luminance or chroma color balance.

Like709 Gamma (ITU-R BT.709) & Knee Control

Broadcast flexibility for post-production.

Luminance Level 64-1023 / 64-940 / 0-1023 (10-bit)

For choice of video luma levels

"LUMIX Tether" Camera Control PC Software

The LUMIX GH5s allows tethered shooting via USB with "LUMIX Tether" PC software. It enables camera control and shooting while checking the image on a large PC screen. Plus it supports both video and 4K PHOTO, to greatly assists professional workflows in commercial photoshoots.

Dual SD Card Slots

The LUMIX GH5s is equipped with dual SD card slots for larger capacity recording and efficient file arrangement. Relay mode allows you to swap a full card out for an empty card so you can virtually record endlessly. Backup mode allows you to record continuously on one card, while you start and stop recording on the other card. Simultaneous record mode duplicates your recording on both cards. Both slots are compatible with high-speed, high-capacity UHS-II Video Speed Class 60 cards for high bitrate video recording.

Max.10x Slow Motion Video VFR

The VFR (Variable Frame Rate) lets you record videos with dramatic slow motion or unique quick motion in C4K/4K (60-fps maximum 2.5x slower*) or Full HD (240-fps maximum 10x slower*) quality. * In 24p playback. Effect value varies depending on the recording format and frequency. The angle of view narrows if you select a frame rate with a number of frames greater than 204-fps.

C4K/4K 60p/50p Smooth Quality Video

The LUMIX GH5s takes professional shooting performance to another level with high-precision, silky smooth 4K 60p/50p (Cinema 4K: 4096 x 2160 / QFHD 4K: 3840 x 2160 / MOV or MP4) video recording capability.

Faster frame rates mean excellent motion compensation plus you can slow down footage inside your video editing timeline without losing detail. You also achieve perfect panning control and a suppression of the rolling shutter effect as seen in lesser frame rates.

Perfect focal length can also be achieved as the LUMIX GH5s features a multiple aspect ratio recording. There's also no recording duration limit so you can go beyond 30 minutes in all record settings.

TC IN/OUT Terminal

The time code can be synchronized with an external device by using the bundled BNC conversion cable. This enables more precise image production for movies and documentaries, where multiple cameras are essential.

LINE Input Supported

LINE input is supported by Φ3.5mm mic jack. This makes it possible to input sounds from an external audio device, for more efficient video production.

Pre-installed V-LogL Video Recording Function

A neutral or flat logarithmic ("log") gamma curve captures wide dynamic range pictures ideal for color grading. Plus, a LUT Display function assists your exposure and helps to show directorial intent (e.g., use V-Log to Rec.709 LUT for an HDTV look).

Hybrid Log Gamma for 4K HDR Video

HDR (High Dynamic Range) is a mode to reproduces both the bright parts and dark parts of an image, making it look just as the human eyes sees it. You can choose Hybrid Log Gamma (HLG) in Photo Style.

WIRELESS WiFi Wi-Fi2.4GHz (STA/AP) (IEEE802.11b/g/n)/Wi-Fi5GHz (STA) (IEEE 802.11a/n/ac)*5GHz Wi-Fi is not available in some countries./1-13, 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140 ch
Bluetooth Bluetooth® v4.2 (Bluetooth Low Energy (BLE))
QR code connection / Password-less connection Yes / Yes (ON / OFF selectable)
VIEWFINDER Type OLED Live View Finder (3,680k dots)
Field of view Approx. 100%
Magnification Approx. 1.52x / 0.76x (35mm camera equivalent) with 50 mm lens at infinity; -1.0 m-1
Eye point Approx. 21 mm from eyepiece lens
Diopter adjustment -4.0 - +3.0 (dpt)
Eye sensor Yes
Display speed 120fps / 60fps
FOCUS Type Contrast AF system
DFD technology Yes
Post Focus Yes
Focus Stacking Yes
Focus mode AFS (Single) / AFF (Flexible) / AFC (Continuous) / MF
AF mode Face/Eye Detection / Tracking / 225-Area / Custom Multi / 1-Area / Pinpoint/(Full area touch is available) (Scalable AF frame size and flexible AF position)
AF detective range EV -5 - 18 (ISO100 equivalent)
AF assist lamp Yes
AF lock Yes (AF/AE LOCK button)
AF custom setting AF Sensitivity, AF Area Switching Sensitivity, Moving Object Prediction
Others One Shot AF, Shutter AF, Half Press Release, Quick AF, Continuous AF (during motion picture recording), Eye Sensor AF, AF+MF, MF Assist, Touch MF Assist, Focus Peaking, Touch AF/AE Function, Touch Pad AF, Touch Shutter
EXPOSURE CONTROL Light metering system 1,728-zone multi-pattern sensing system
Light metering mode Multiple / Center Weighted / Spot
Metering range EV0-18 (F2.0 lens, ISO100 equivalent)
Exposure mode Program AE, Aperture Priority AE, Shutter Priority AE, Manual
ISO sensitivity (Standard Output Sensitivity) Still image: Auto / Intelligent ISO / 80* / 100* / 160 / 200 / 400 / 800 / 1600 / 3200 / 6400 / 12800 / 25600 / 51200 / 102400* / 204800* (Changeable to 1/3 EV step) *Extended ISO/Creative Video Mode: Auto / 80* / 100* / 160 / 200 / 400 / 800 / 1600 / 3200 / 6400 / 12800 / 25600 / 51200 / 102400* / 204800* (Changeable to 1/3 EV step) *Extended ISO
Dual Native ISO [Normal] Native ISO: 400, 2500/Auto: Auto / 80* / 100* / 160-51200 / 102400* / 204800* (VFR: Auto / 80* / 100* / 160-51200 / 102400* / 204800*) *Extended ISO/Low: Auto / 80* / 100* / 160-800 (VFR: Auto / 80* / 100* / 160-1250) *Extended ISO/High: Auto / 800-51200 / 102400* / 204800* (VFR: Auto / 1250-51200 / 102400* / 204800*) *Extended ISO
[V-LogL] Native ISO: 800, 5000/Auto: Auto / 320-25600 (VFR: Auto / 320-25600)/Low: Auto / 320-1600 (VFR: Auto / 320-2500)/High: Auto / 1600-25600 (VFR: Auto / 2500-25600)
[HLG] Native ISO: 800, 5000/Auto: Auto / 320-51200 / 102400* / 204800* *Extended ISO/Low: Auto / 320-1600/High: Auto / 1600-51200 / 102400* / 204800* *Extended ISO
Exposure compensation 1/3 EV step ±5EV (±3EV for motion picture)
AE lock Yes (AF/AE LOCK button)
WHITE BALANCE White balance AWB / AWBc / Daylight / Cloudy / Shade / incandescent / Flash / White Set 1, 2, 3, 4 / Color temperature setting 1, 2, 3, 4
White balance adjustment Blue/Amber bias, Magenta/Green bias
Color temperature setting 2500-10000K in 100K
SHUTTER Type Focal-plane shutter
Shutter speed Still image: Bulb (Max. 30 minutes), 1/8,000 - 60/Electronic shutter: 1/16,000 - 1/Motion picture: 59.94Hz: 1/16,000 - 1/30, 50.00Hz: 1/16,000 - 1/25, 23.98Hz: 1/16,000 - 1/24 (When using Synchro Scan)
Shutter life Approx. 200,000 images
Self timer 10sec, 3 images / 2sec / 10sec
Remote control Remote control with Bulb function by DMW-RSL1 (sold separately)
BRACKET AE bracket 3, 5, 7 images in 1/3, 2/3 or 1 EV step, max. ±3 EV, single/burst
Aperture Bracket 3, 5 or all positions in 1 EV step
Focus Bracket 1 to 999 images, focus steps can be set in 10 levels
White balance bracket 3 exposures in blue/amber axis or in magenta/green axis, color temperature setting
BURST SHOOTING Burst speed [14-bit]/AFS/MF: H: 11 frames/sec, M: 6 frames/sec (with Live View), L: 2 frames/sec (with Live View) *When H-ES12060 is used./AFF/AFC: H: 7 frames/sec (with Live View), M: 5 frames/sec (with Live View), L: 2 frames/sec (with Live View) *When H-ES12060 is used./[12-bit]/AFS/MF: H: 12 frames/sec, M: 7 frames/sec (with Live View), L: 2 frames/sec (with Live View) *When H-ES12060 is used./AFF/AFC: H: 8 frames/sec (with Live View), M: 6 frames/sec (with Live View), L: 2 frames/sec (with Live View) *When H-ES12060 is used.
Number of recordable images More than approx. 80 images (when there are RAW files with the particular speed.)/More than approx. 600 images (when there are no RAW files and using a card with SD Speed Class with "UHS-II UHS Speed Class 3 (U3)".)/(depending on memory card size, battery power, picture size, and compression)
4K PHOTO** Burst speed 60 frames/sec, 30 frames/sec
Exif information Yes (Each JPEG image cropped out of the 4K burst file complies with EXIF.)
Marking function Yes (in 4K Burst (S/S) mode)
Loop rec function Yes (in 4K Burst (S/S) mode)
FLASH Flash type TTL External Flash (sold separately)
Flash Mode Auto*, Auto/Red-eye Reduction*, Forced On, Forced On/Red-eye Reduction, Slow Sync., Slow Sync./Red-eye Reduction, Forced Off *For iA, iA+ only.
Synchronization speed Less than 1/250 second
Flash output adjustment 1/3EV step ±3EV
Flash synchronization 1st Curtain Sync, 2nd Curtain Sync.
Synchronization for flash dimming and exposure compensation Yes
Wireless control Yes (When using DMW-FL200L / FL360L / FL580L (sold separately)), Wireless Channel: 1ch/2ch/3ch/4ch
Flash sync socket Yes
REAR MONITOR Type TFT LCD monitor with static touch control
Monitor size Free-angle 3.2-inch (8.0cm) / 3:2 aspect
Pixels Approx. 1,620k dots
Filed of view Approx. 100%
Monitor adjustment Brightness, Contrast, Saturation, Red-Green, Blue-Yellow
Anamorphic 4K mode (4:3) MP4** 59.94Hz <3328x2496>59.94p, 150Mbps (4:2:0 8-bit LongGOP) (LPCM)/<3328x2496>29.97p, 400Mbps (4:2:2 10-bit ALL-Intra) (LPCM)/<3328x2496>29.97p, 150Mbps (4:2:2 10-bit LongGOP) (LPCM) / 100Mbps (4:2:0 8-bit LongGOP) (LPCM)/<3328x2496>23.98p, 400Mbps (4:2:2 10-bit ALL-Intra) (LPCM)/<3328x2496>23.98p, 150Mbps (4:2:2 10-bit LongGOP) (LPCM) / 100Mbps (4:2:0 8-bit LongGOP) (LPCM)
MP4** 50.00Hz <3328x2496>50.00p, 150Mbps (4:2:0 8-bit LongGOP) (LPCM)/<3328x2496>25.00p, 400Mbps (4:2:2 10-bit ALL-Intra) (LPCM)/<3328x2496>25.00p, 150Mbps (4:2:2 10-bit LongGOP) (LPCM) / 100Mbps (4:2:0 8-bit LongGOP) (LPCM)
MP4** 24.00Hz <3328x2496>24.00p, 400Mbps (4:2:2 10-bit ALL-Intra) (LPCM)/<3328x2496>24.00p, 150Mbps (4:2:2 10-bit LongGOP) (LPCM) / 100Mbps (4:2:0 8-bit LongGOP) (LPCM)
MOV** / *****-59.94Hz <3328x2496>59.94p, 150Mbps (4:2:0 8-bit LongGOP) (LPCM, High-Res Audio)/<3328x2496>29.97p, 400Mbps (4:2:2 10-bit ALL-Intra) (LPCM, High-Res Audio)/<3328x2496>29.97p, 150Mbps (4:2:2 10-bit LongGOP) (LPCM, High-Res Audio) / 100Mbps (4:2:0 8-bit LongGOP) (LPCM, High-Res Audio)/<3328x2496>23.98p, 400Mbps (4:2:2 10-bit ALL-Intra) (LPCM, High-Res Audio)/<3328x2496>23.98p, 150Mbps (4:2:2 10-bit LongGOP) (LPCM, High-Res Audio) / 100Mbps (4:2:0 8-bit LongGOP) (LPCM, High-Res Audio)
MOV** / *****-50.00Hz <3328x2496>50.00p, 150Mbps (4:2:0 8-bit LongGOP) (LPCM, High-Res Audio)/<3328x2496>25.00p, 400Mbps (4:2:2 10-bit ALL-Intra) (LPCM, High-Res Audio)/<3328x2496>25.00p, 150Mbps (4:2:2 10-bit LongGOP) (LPCM, High-Res Audio) / 100Mbps (4:2:0 8-bit LongGOP) (LPCM, High-Res Audio)
MOV** / *****-24.00Hz <3328x2496>24.00p, 400Mbps (4:2:2 10-bit ALL-Intra) (LPCM, High-Res Audio)/<3328x2496>24.00p, 150Mbps (4:2:2 10-bit LongGOP) (LPCM, High-Res Audio) / 100Mbps (4:2:0 8-bit LongGOP) (LPCM, High-Res Audio)
LIVE VIEW Digital zoom 2x, 4x
Extra Tele Conversion Still image: Max. 2x/Motion picture: 2.1x (FHD)
Other functions Level Gauge, Real-time Histogram, Guide Lines (3 patterns), Video Guide Line, Center Marker, Highlight display (Still image / motion picture), Zebra pattern (Still image / motion picture)
DIRECTION DETECTION FUNCTION Direction Detection Function Yes
FUNCTION BUTTON REC Wi-Fi / Q.MENU / Video Record / LVF/Monitor Switch / LVF/Monitor Disp. Style / AF/AE LOCK / AF-ON / Preview / One Push AE / Touch AE / Level Gauge / Focus Area Set / Zoom Control / 1 Shot RAW+JPG / 1 Shot Spot Metering / 1 Shot 4K PHOTO / Operation Lock / Dial Operation Switch / Destination Slot / Photo Style / Filter Select / Aspect Ratio / Picture Size / Quality / RAW Bit Size / AFS/AFF / Metering Mode / Burst Rate / 4K PHOTO / Self Timer / Bracket / Highlight Shadow / i. Dynamic / i. Resolution / Min. Shtr Speed / HDR / Shutter Type / Flash Mode / Flash Adjust. / Wireless Flash Setup / Ex. Tele Conv. / Digital Zoom / Stabilizer / 4K Live Cropping / Motion Pic. Rec Format / Motion Pic. Rec Quality / Variable Frame Rate / Picture Mode in Rec. / Synchro Scan / Time Code Display / Sound Rec Level Adj. / Mic. Directivity Adjust / HLG View Assist (HDMI) / Color Bars / WFM/Vector Scope / Anamorphic Desqueeze Display / HLG View Assist / LUT Monitor Display / LUT HDMI Display / Focus Transition / Silent Mode / Peaking / Histogram / Guide Line / Video Guide Line / Zebra Pattern / Monochrome Live View / Constant Preview / Live View Boost / Rec Area / Video-Priority Display / Step Zoom / Zoom Speed / Night Mode / Exposure Comp. / Sensitivity / White Balance / ON/OFF of each item in White Balance / ON/OFF of each item in Photo Style / AF Mode/MF / Rec/Playback Switch / Off / Restore to Default
PLAY Wi-Fi / LVF/Monitor Switch / Rec/Playback Switch / Slot Change / 4K PHOTO Play / Delete Single / Protect / Rating 1, 2, 3, 4, 5 / RAW Processing / 4K PHOTO Bulk Saving / Copy / Anamorphic Desqueeze Display / HLG View Assist / HLG View Assist (HDMI) / LUT Monitor Display / LUT HDMI Display / Night Mode / Off / Restore to Default
PHOTO STYLE Photo Style Standard / Vivid / Natural / Monochrome / L. Monochrome / Scenery / Portrait / Custom 1, 2, 3, 4 / Cinelike D / Cinelike V / Like709 / Hybrid Log Gamma* / V-LogL/*When Creative Video Mode is selected.
CREATIVE CONTROL Creative Control Expressive / Retro / Old Days / High Key / Low Key / Sepia / Monochrome / Dynamic Monochrome / Rough Monochrome* / Silky Monochrome* / Impressive Art / High Dynamic / Cross Process / Toy Effect / Toy Pop / Bleach Bypass / Miniature Effect** / Soft Focus* / Fantasy / Star Filter* / One Point Color / Sunshine*/*For photos only. **Not available in 4:2:2 10-bit video or C4K/4K video recording.
VARIABLE FRAME RATE 59.94Hz MOV/MP4(LPCM)/FHD/59.94p/2, 30, 56, 58, 60, 62, 64, 90, 120, 150, 180, 210, 240 fps/MOV/MP4(LPCM)/4K/29.97p, MOV/MP4(LPCM)/C4K/29.97p, AVCHD/FHD/29.97p/2, 15, 26, 28, 30, 32, 34, 45, 60 fps/MOV/MP4(LPCM)/FHD/29.97p/2, 15, 26, 28, 30, 32, 34, 45, 60, 75, 90, 105, 120, 135, 150, 165, 180, 195, 210, 225, 240 fps/MOV/MP4(LPCM)/4K/23.98p, MOV/MP4(LPCM)/C4K/23.98p, AVCHD/FHD/23.98p/2, 12, 20, 22, 24, 26, 28, 36, 48, 60 fps/MOV/MP4(LPCM)/FHD/23.98p/2, 12, 20, 22, 24, 26, 28, 36, 48, 60, 72, 84, 96, 108, 120, 132, 144, 156, 168, 180, 192, 204, 216, 228, 240 fps
50.00Hz MOV/MP4(LPCM)/FHD/50.00p/2, 25, 46, 48, 50, 52, 54, 75, 100, 125, 150, 200, 240 fps/MOV/MP4(LPCM)/4K/25.00p, MOV/MP4(LPCM)/C4K/25.00p, AVCHD/FHD/25.00p/2, 12, 21, 23, 25, 27, 30, 37, 60 fps/MOV/MP4(LPCM)/FHD/25.00p/2, 12, 21, 23, 25, 27, 30, 37, 50, 62, 75, 87, 100, 112, 125, 137, 150, 175, 200, 225, 240 fps
24.00Hz MOV/MP4(LPCM)/C4K/24.00p, MOV/MP4(LPCM)/4K/24.00p/2, 12, 20, 22, 24, 26, 28, 36, 48, 60 fps/MOV/MP4(LPCM)/FHD/24.00p/2, 12, 20, 22, 24, 26, 28, 36, 48, 60, 72, 84, 96, 108, 120, 132, 144, 156, 168, 180, 192, 204, 216, 228, 240 fps
MOTION PICTURE FUNCTION Master pedestal level 31 steps
Luminance level 8-bit: 0-255 / 16-235 / 16-255/10-bit: 0‒1023 / 64‒940 / 64‒1023
Wave form monitor / Vectorscope Selectable
LUT display LUT Monitor Display / LUT HDMI Display
Synchro scan Yes
Time code Count Up: Rec Run/Free Run selectable, Time Code Mode: Drop frame/Non-drop frame selectable (When system frequency [59.94Hz] is selected.)
SS/Gain operation Shutter Duration/ISO / Angle/ISO / Shutter Duration/dB
Color bars / 1kHz test tone Yes (SMPTE / EBU / ARIB) / Yes
Knee control Yes (in Like709 mode)
PLAYBACK Playback mode 30-thumbnail display, 12-thumbnail display, Calendar display, Zoomed playback (Max. 16x), Slideshow (All / Picture Only / Video Only, duration & effect is selectable), Playback Mode (Normal / Picture Only / Video Only), Protect, Rating, Title Edit, Face Recognition Edit, RAW Processing, 4K PHOTO Bulk Saving, 4K PHOTO Noise Reduction, Light Composition, Clear Retouch, Text Stamp, Copy, Resize, Cropping, Rotate, Video Divide, Time Lapse Video, Stop Motion Video, Rotation Display, Anamorphic Desqueeze Display, HLG View Assist, LUT Monitor Display, Picture Sort, Delete Confirmation, Creating Still Pictures from a Motion Picture
IMAGE PROTECTION / DELETE Protection Single / Multi or Cancel
Delete Single / Multi / All / Except Rating
PRINT PictBridge compatible
INTERFACE USB USB Type-C, SuperSpeed USB 3.1 Gen1
HDMI*** Monitor-through 4:2:2 10-bit (When [Rec Quality] is set to [4:2:2 10bit] or when [Rec Quality] is set to [C4K/60p]/[C4K/50p]/[4K/60p]/[4K/50p] and [4K/60p Bit Mode]/[4K/50p Bit Mode] is set to [4:2:2 10bit]. When [C4K/60p]/[C4K/50p]/[4K/60p]/[4K/50p] mode is selected in [Rec Quality], it is not possible to record motion picture or still picture on the SD memory card in the camera unit.)/4:2:2 8bit (When [Rec Quality] is set to [4:2:0 8bit], except for [C4K/60p]/[C4K/50p]/[4K 60p]/[4K/50p])/4:2:0 8bit (When [Rec Quality] is set to [C4K/60p]/[C4K/50p]/[4K/60p]/[4K/50p] and [4K/60p Bit Mode]/[4K/50p Bit Mode] is set to [4:2:0 8bit].)/Auto / 4K/30p/25p / 1080p / 1080i / OFF/Information display ON/OFF (selectable)/HLG View Assist (HDMI) AUTO / MODE1 / MODE2 / OFF (selectable)/Automatic down-conversion
Playback HDMI TypeA / VIERA Link, Audio: Stereo/59.94Hz: Auto / C4K/60p / C4K/30p / 4K/60p / 4K/30p / 1080p / 1080i / 720p / 480p/50.00Hz: Auto / C4K/50p / C4K/25p / 4K/50p / 4K/25p / 1080p / 1080i / 720p / 576p/24.00Hz: Auto / C4K/24p / 4K/24p / 1080p
Audio video output No
Remote input φ2.5mm for remote
External microphone / external audio device input φ3.5mm for external microphone / external audio device/MIC (Plug-in Power) / MIC / LINE is selectable./Stereo/Lens Auto/Shotgun/Super Shotgun/Manual is selectable when attaching DMW-MS2 (sold separately).
Headphone output φ3.5mm for headphone
Microphone Stereo, Wind Noise Canceller: OFF / Low* / Standard / High *When attaching DMW-MS2 (sold separately).
High-res audio recording Yes with DMW-XLR1 (sold separately)
Speaker Monaural
SD card slot Slot 1, Slot 2
TC IN/OUT Yes with BNC Converter Cable (bundled)
LANGUAGE OSD language Japanese, English, German, French, Italian, Spanish, Polish, Czech, Hungarian, Romanian, Netherlandic, Turkish, Portuguese, Finnish, Danish, Swedish, Greek
POWER Battery Li-ion Battery Pack (7.2V, 1860mAh, 14Wh) (bundled)
Battery life (CIPA standard) Approx. 440 images (rear monitor), 410 images (LVF), 1,300 images (Power Save LVF mode*) with H-FS12060/*Under the test conditions specified by Panasonic based on CIPA standard. When the time to get in the sleep mode is set to 1 sec
Battery grip DMW-BGGH5 (sold separately)
DIMENSIONS / WEIGHT Dimensions (W x H x D) 138.5 x 98.1 x 87.4 mm / 5.45 x 3.86 x 3.44 inch (excluding protrusions)
Weight Approx. 660g / 1.46 lb (SD card x 1, Battery, Body)/Approx. 580g / 1.28 lb (Body only)
OPERATING ENVIRONMENT Operating temperature**** -10oC to 40oC (14oF to 104oF)
Operating humidity 10%RH to 80%RH
STANDARD ACCESSORIES Software Recording LUMIX Tether/・ This software is used to control a Panasonic digital camera from a PC. It allows you to change various settings of the camera, perform remote recording, and save remotely recorded images to the PC. Check the site below to download and install the software./http://panasonic.jp/support/global/cs/soft/download/d_lumixtether.html (For Windows / Mac)
Playback / Editing ・ The software to edit and playback images on computer is not bundled with this camera. To do this, PHOTOfunSTUDIO 10.0XE is available for download at Panasonic website using computer connected to the Internet./http://panasonic.jp/support/global/cs/soft/download/d_pfs99pe.html (For Windows)/・ The software to process RAW file on computer is not bundled with this camera. To do this, SILKYPIX Developer Studio is available for download at Ichikawa Soft Laboratory's website using computer connected to the Internet./http://www.isl.co.jp/SILKYPIX/english/p/ (For Windows / Mac)
Standard accessories Battery Charger (AC Adaptor), Battery Pack, Body Cap, Hot Shoe Cover, Eye Cup, Flash Synchro Socket Cap, Cover for the Battery Grip Connector, USB Connection Cable, Shoulder Strap, Cable Holder, BNC Converter Cable/・ The DC-GH5S Operating Instructions for advanced features is available for downloaded at Panasonic LUMIX Customer Support Site using PC, smartphone or tablet connected to the Internet.
NOTE ** About motion picture recording / 4K PHOTO recording
NOTE - Use a card with SD Speed Class with "Class 4" or higher when recording motion pictures in [AVCHD] or [MP4(under 28Mbps)].
NOTE - Use a card with SD Speed Class with "UHS-I / UHS-II UHS Speed Class 3 (U3)" when recording motion pictures with [MP4] in [C4K] [4K], [MOV] or [4K PHOTO].
NOTE (SD speed class is the speed standard regarding continuous writing.)
NOTE - Video Speed Class 60 or higher is required for ALL-Intra 400Mbps recording. Use of SD Memory Card with Video Speed Class 60 or higher is recommended for C4K/4K ALL-Intra video recording.
NOTE - MP4 motion pictures with [MP4] in [C4K] [4K]:
NOTE - When using an SDHC memory card: You can continue recording without interruption even if the file size exceeds 4 GB, but the motion picture file will be divided and recorded/played back separately.
NOTE - When using an SDXC memory card: You can continue recording without interruption even if the file size exceeds 96 GB or 3 hours 4 minutes in length, but the motion picture file will be divided and recorded/played back separately.
NOTE - MP4 motion pictures with [MP4] in [FHD]:
NOTE - You can continue recording without interruption even if the file size exceeds 4 GB or 30 minutes in length, but the motion picture file will be divided and recorded/played back separately.
NOTE - 4:2:2 10-bit recording is a recording mode for film production and the video needs to be processed on PC.
NOTE The original video cannot be played on standard TV, Blu-ray Disc™ recorder and Blu-ray Disc™ player.
NOTE It may cause problems such as freezing when played on these devices.
NOTE *** For [C4K/60p] [C4K/50p] [4K/60p] [4K/50p] video output, use an HDMI2.0 cable that has the HDMI logo on it, and that is described as"4K compatible".
NOTE **** The camera may stop recording when used in lower or higher than recommended operating temperature: -10 to 40 degrees.
NOTE ***** High-res audio is selectable only when using the DMW-XLR1 (sold separately).
