General |
|
Power |
DC 7.2 V (when the battery is used)
DC 12 V (when the AC adaptor is used) |
Power Consumption |
TBA |
Operating Temperature |
0 °C to 40 °C (32 °F to 104 °F) |
Operating Humidity |
10 % to 80 % (no condensation) |
Weight |
Approx. 2.7 kg (5.9 lbs)
(body only, excluding lens hood, battery, and accessories) |
Dimensions |
181 mm(H) x 216 mm(W) x 374 mm (D) excluding protrusions(7-1/8 inches x 8-1/2 inches x 14-23/32 inches) |
Camera Unit |
|
Pickup Device |
4/3-type MOS |
Effective Pixels |
1549 megapixcel (FHD), 871 megapixcel (UHD/59.94p), 1289 megapixcel (UHD/29.97p), 1335 megapixcel (4K/24p) |
Lens |
Optical image stabilizer lens with motorized/manual mode switching, 13x zoom, F2.8 to F4.5 (f=12.8 mm to 167 mm) 35 mm equivalent: 28.0 mm to 365.3 mm (FHD) |
Filter Diameter |
72 mm |
ND Filter |
OFF, 1/4, 1/16, 1/64 |
Shortest Shooting Distance |
Approx. 1.0 m from the front lens(.M.O.D) |
Gain Setting |
L/M/H selector switch 0 dB to 24 dB in 1 dB steps |
Color Temperature Setting |
ATW, ATW LOCK, Ach, Bch, preset 3200 K/preset 5600 K/VAR (2000 K to 15000 K) |
Shutter Speed |
When [SYSTEM MODE] = 59.94 Hz
60i/60p mode: 1/60 sec., 1/100 sec., 1/120 sec., 1/180 sec., 1/250., 1/350., 1/500 sec., 1/750 sec •
,.1/1000 sec.,1/1500 sec.,1/2000 sec.,1/3000 sec
.1/4000 sec.,1/8000 sec
30p mode: 1/30 sec.,1/50 sec.,1/60 sec., 1/100 sec., 1/120 sec., 1/180 sec., 1/250 sec., 1/350 sec., 1/500 sec •
,.1/750 sec., 1/1000 sec., 1/1500 sec., 1/2000 sec
.1/3000 sec.,1/4000 sec., 1/8000 sec
24p mode: 1/24 sec., 1/48 sec., 1/50 sec., 1/60 sec., 1/100 sec., 1/120 sec., 1/180 sec., 1/250 sec., 1/350 sec •
,.1/500 sec., 1/750 sec., 1/1000 sec., 1/1500 sec., 1/2000 sec., 1/3000 sec., 1/4000 sec., 1/8000 sec
When [SYSTEM MODE] = 50 Hz
50i/50p mode: 1/50 sec., 1/60 sec., 1/100 sec., 1/125 sec., 1/180 sec., 1/250 sec., 1/350 sec., 1/500 sec., 1/750 sec •
,.1/1000 sec., 1/1500 sec., 1/2000 sec., 1/3000 sec., 1/4000 sec., 1/8000 sec
25p mode: 1/25 sec., 1/50 sec., 1/60 sec., 1/100 sec., 1/125 sec., 1/180 sec., 1/250 sec., 1/350 sec., 1/500 sec •
,.1/750 sec., 1/1000 sec., 1/1500 sec., 1/2000 sec., 1/3000 sec., 1/4000 sec., 1/8000 sec |
Slow Shutter Speed |
When [SYSTEM MODE] = 59.94 Hz
60i/60p mode: 1/2 sec., 1/4 sec., 1/8 sec., 1/15 sec., 1/30 sec
30p mode: 1/2 sec., 1/4 sec., 1/8 sec., 1/15 sec.
24p mode: 1/2 sec., 1/3 sec., 1/6 sec., 1/12 sec
When [SYSTEM MODE] = 50 Hz
50i/50p mode: 1/2 sec., 1/3 sec., 1/6 sec., 1/12 sec., 1/25 sec
25p mode: 1/2 sec., 1/3 sec., 1/6 sec., 1/12 sec |
Synchro Scan Shutter |
When [SYSTEM MODE] = 59.94 Hz
60i/60p mode: 1/60.0 sec. to 1/249.8 sec.
30p mode: 1/30.0 sec. to 1/249.8 sec.
24p mode: 1/24.0 sec. to 1/249.6 sec.
When [SYSTEM MODE] = 50 Hz
50i/50p mode: 1/50.0 sec. to 1/250.0 sec.
25p mode: 1/25.0 sec. to 1/250.0 sec. |
Shutter Open Angle |
5.0 deg to 180.0 deg to 360.0 deg (in 0.5 deg steps, angle display) |
VFR Recording Frame Rate |
When [SYSTEM MODE] = 59.94 Hz
60p mode: 2, 15, 30, 40, 55, 58, 60, 62, 65, 75, 90, and 120 frames per second
30p mode: 2, 15, 26, 28, 30, 32, 34, 45, 60, 75, 90, and 120 frames per second
24p mode: 2, 12, 18, 20, 22, 24, 26, 28, 30, 36, 48, 60, 72, 84, 96, and 120 frames per second
When [SYSTEM MODE] = 50 Hz
50p mode: 2, 12, 25, 33, 45, 48, 50, 52, 55, 62, 75, 100 and 120 frames per second
25p mode: 2, 12, 21, 23, 25, 27, 30, 37, 50, 62, 75, 100 and 120 frames per second |
Minimum Subject Illumination |
0.2 lx (F2.8, gain 18 dB, [1/2S.], Manual slow shutter HIGH SENS. mode) |
Horizontal Resolution |
1000 TV or higher (center) |
Digital Zoom |
x2, x5, x10 |
Lens Hood |
Hood with lens cover |
Memory Card Recorder |
Recording Media: SDHC memory card (4 GB to 32 GB)
SDXC memory card (48 GB to 128 GB), UHS-I supported
When recording video images at 100 Mbps or higher, an SD memory card compatible with UHS Speed Class 3 (U3) is required |
Recording Slot |
Slot x 2 |
System Format |
59.94 Hz (NTSC) / 50 Hz (PAL) |
Video Recording Format |
Recording Format: MOV, MP4, AVCHD |
Still Picture Recording Format |
JPEG (DCF/Exif2.2) supported
(8.8M: 4096 x 2160 (17:9), 8.3M: 3840 x 2160 (16:9)
2.1M: 1920 x 1080 (16:9), 0.9M: 1280 x 720 (16:9)
0.2M: 640 x 360 (16:9), 0.3M: 640 x 480 (4:3) |
Digital Video |
|
External Output Video Signal |
8 bit 4:2:2/10 bit 4:2:2 (switchable menu)
HDMI output of UHD/59.94p/50.00p becomes 8 bit 4:2:0. Also, when 10 bit 4:2:2 is selected, recording is not possible with the main unit. |
Recording Video Signal |
8 bit 4:2:0 |
Video Compression Format |
MPEG-4 AVC/H.264 High Profile (MOV/MP4/AVCHD) |
Recording Mode (System Frequency 59.94 Hz) |
|
MOV/MP4 |
4K 4096 x 2160/24.00p 100 Mbps
3840x 2160/29.97p/23.98p 100 Mbps
FHD
1920x1080/59.94p/29.97p/23.98p (ALL-I) 200 Mbps
1920x1080/59.94p 100 Mbps
1920x1080/50.00p 100 Mbps
1920x1080/59.94p/29.97p/23.98p/59.94i 50 Mbps |
AVCHD |
PS 1920x1080/59.94p 25 Mbps
PS 1920x1080/59.00p 25 Mbps
PH 1920x1080/59.94i/23.98p 21 Mpbs
PH 1920x1080/50.00i/25.00p 21 Mpbs
HA 1920x1080/59.94i 17 Mbps
HA 1920x1080/50.00i 17 Mbps
HE 1440x1080/59.94i 5 Mbps
HE 1440x1080/50.00i 5 Mbps
PM 1280x720/59.94p 8 Mbps
PM 1280x720/50.00p 8 Mbps
SA 720x480/59.94i/SIDE CROP/LETTERBOXSQUEEZE 9 Mbps |
Recording Mode (System Frequency 50 Hz) |
|
4K |
4096x 2160/24.00p 100 Mbps |
UHD |
3840x 2160/50.00p 150 Mbps
3840x 2160/25.00p 100 Mbps |
FHD |
1920x1080/50.00p/25.00p (ALL-I) 200 Mbps
100 Mbps 1920x1080/50.00p 100 Mbps
1920x1080/50.00p/25.00p/50.00i 50 Mbps |
AVCHD |
PS 1920x1080/59.00p 25 Mbps
PH 1920x1080/50.00i/25.00p 21 Mpbs
HA 1920x1080/50.00i 17 Mbps
HE 1440x1080/50.00i 5 Mbps
PM 1280x720/50.00p 8 Mbps
SA 720x576/50.00i/SIDE CROP/LETTERBOX/SQUEEZE 9 Mbps SA |
Digital Audio |
|
Recording Audio Signal |
48 kHz/16 bit, 2 CH |
Audio Compression Format |
LPCM (MOV/MP4) Dolby Digital (AVCHD) |
Headroom |
12 dB/18 dB/20 dB (switchable menu) |
Dual Codec |
|
File Format |
MOV, MP4 |
Video Compression Format |
MPEG-4 AVC/H.264 High Profile |
Audio Compression Format |
LPCM |
Recording Format |
When [Dual Codec] = FHD 50 Mbps
[Main Recording Side]
Recording mode = MOV/MP4
UHD/29.97p/25.00p/23.98p 100 Mbps
[Sub Recording Side]
= Recording mode
Same as the recording mode of the Main Recording Side
FHD/29.97p/25.00p/23.98p 50Mbps
When [Dual Codec] = FHD 8Mbps
[Main Recording Side]
Recording mode = MOV/MP4
UHD/29.97p/25.00p/23.98p 100 Mbps
FHD/59.94p/50.00p/29.97p/25.00p/23.98p 200 Mbps
FHD/59.94p/50.00p 100 Mbps
[Sub Recording Side]
Recording mode = MOV
FHD/59.94p/50.00p/29.97p/25.00p/23.98p 8 Mbps |
Video Input/Output |
|
SDI OUT |
BNC x1, 0.8 V [p-p], 75 Ω, 3 G/1.5 G HD-SDI, SD-SDI supported, Output format: 1080/59.94p LEVEL-A/50.00p LEVEL-A, 1080/29.97PsF/25.00PsF/24.00PsF/23.98PsF, 1080/59.94i/50.00i, 720/59.94p/50.00p, 480/59.94i, 576/50.00i |
VIDEO OUT |
BNC x 1, Composite 1.0 V [p-p], 75 Ω |
HDMI OUT |
HDMI x 1
(HDMI type A terminal, not compatible with VIERA Link)
Output format: 2160/59.94p/50.00p/29.97p/25.00p/24.00p/23.98,1080/59.94p/50.00p/29.97p/25.00p/24.00p/23.98p/59.94i/50.00i,720/59.94p/50.00p, 480/59.94p, 576/50.00p |
Audio Input |
|
Built-in Microphone |
Supports stereo microphone |
XLR IN |
XLR (3 pin) x 2 (INPUT1, INPUT2) Input high impedance
LINE/MIC/MIC+48 V switchable SW
LINE: 4 dBu/0 dBu switchable menu
MIC: -40 dBu/ -50 dBu/ -60 dBu menu |
Audio Output |
|
SDI OUT |
2 CH (LPCM) switchable gain: 0 dB/-6 dB/-12 dB |
HDMI OUT |
2 CH (LPCM) |
Audio OUT |
3.5 mm diameter stereo mini jack x 1, Output level: 600 Ω, 316 mV |
Headphone |
3.5 mm diameter stereo mini jack x 1 |
Speaker |
20 mm diameter, round x 1 |
Other Input/Output |
|
CAM REMOTE |
2.5 mm diameter super mini jack x1 (ZOOM, S/S)
3.5 mm diameter mini jack x1 (FOCUS, IRIS) |
TC PRESET IN/OUT |
BNC x 1 Used as the input and output terminals, IN/OUT switch selection
Input: 1.0 V to 4.0 V [p-p], 10 kΩ
Output: 2.0 V ±0.5 V [p-p], low impedance |
USB 3.0 HOST |
Standard-A connector, 9 pin
USB hard disk connected function, Bus power supply. A USB hard disk of 32 GB or less, or exceeding 2TB cannot be used |
USB 3.0 DEVICE |
Micro-B connector, 10 pin, Mass storage function (read only) |
DC IN 12 V |
DC 12 V (11.4 V to 12.6 V), EIAJ type 4 |
Monitor/Viewfinder |
|
LCD Monitor |
4.3 type HD color monitor (Approx. 2760000 dots) |
Viewfinder |
0.39 type OLED (Approx. 2360000 dots, video display area: Approx. 1770000 dots) |
General |
|
Included Accessories |
Battery (VW-VBD58), Shoulder strap, Battery charger, Microphone holder, AC adaptor, Screw for microphone holder (12 mm), Power code x 2, Eye cup, Lens hood, INPUT terminal cap, CD-ROM (Operating Instructions) |
|
