Fujinon 2.5-25mm T3.5 Iconix HD-RH1 Lens

Fujinon lens for the Iconix HD-RH1.

For purchasing information

Fujinon C mount lens for 1/3" 3CCD cameras (Iconix HD-RH1).

There is no media for this item.

Specifications
Operation
Zoom		Manual
Focus		Manual
Iris		Manual
Focal Length (mm)		25mm
Iris Range		F2.2 ~ F16 * Close
Back Focal Distance (in air) (mm)		15.12
Exit Pupil Position (From Image Plane) (mm)		-120
Filter Thread (mm)		M25.5 x 0.5
Remarks		Designed for optimizing 3CCD Cameras
Focusing Range (From Front Of The Lens) (m)		∞ ~ 0.2
Mass (kg)		60
1/3"
Angle of View	Wide	10°58' x 8°14'
Object Dimensions at M.O.D.	1/3"	42 x 32
