Convergent Design Odyssey 7Q+

Item Code: NMA/CD-ODYSSEY7Q+

The Odyssey7Q+ is the most advanced, most capable, most versatile monitor/recorder in the world. The Odyssey7Q+ can record HD/2K/UHD/4K.

RRP: 0   Save:

  • Qty:
  • Price:
    $2,310.00
    inc. GST

Found this item cheaper elsewhere? Let us know

The Odyssey7Q+ is the most advanced, most capable, most versatile monitor/recorder in the world. It can record HD/2K/UHD/4K via SDI and HDMI, as well as RAW (with Record Options), uncompressed DPX, and Apple ProRes 422 (HQ).

  • HD/2K/UHD/4K
  • 4K/UHD capture over HDMI or SDI
  • SDI Single/Dual/Quad Link
  • RAW to Apple ProRes Conversion
  • 4K/UHD->2K/HD conversion
  • Low Power/Light Weight
  • Intuitive touchscreen interface

The Most Versatile Monitor/Recorder In The Industry

OLED Monitor With Tools, RAW and Video Recorder For HD Thru 4K, Multi-Stream Monitor/Switcher

The Odyssey7Q+ is the most advanced, most capable, most versatile monitor/recorder in the world. The Odyssey7Q+ can record HD/2K/UHD/4K. It can record them via SDI and HDMI. It can record RAW (with Record Options), uncompressed DPX, and Apple ProRes 422 (HQ). The Odyssey7Q+ features an OLED 1280x800 monitor with true blacks, accurate colors, extended color gamut and a 176 degree viewing angle.

Along with the best image in the industry, the Odyssey7Q+ also features an extensive array of image analysis tools, including an RGB waveform, RGB Histogram, False Color, Pixel Zoom with finger drag, three-mode Focus Assist and monitoring LUTs.

The unique Multi-Stream Monitoring mode allows up to four HD video inputs to be viewed at once in a quad-split view or to be live-switched between in full screen. The Odyssey7Q+ weighs a little over one pound, is just one inch thick and can run on any power source from 6.5-34 volts.

Monitoring

The Odyssey7Q+ features a 7.7” OLED screen with 1280x800 resolution. The OLED display provides true blacks and accurate colors. A full complement of image analysis tools include a waveform (luma or RGB parade), a histogram (luma or RGB parade), zebra, programmable False Color, Pixel Zoom with finger drag, a three-mode Focus Assist and LUTs. The included LUTs provide proper viewing of the LOG and RAW modes available from numerous popular cameras, with programmable LUTs coming in the future. These tools are controlled by the easy to use touchscreen interface and are available to view on the OLED or optionally on the SDI and HDMI video outputs of the Odyssey7Q+.

Recording

The Odyssey7Q+ is able to record more formats and signal types than any other recorder in the world. Included in the Odyssey7Q+ is Apple ProRes 422 (HQ) recording in HD/2K up to 60p and UHD/4K up to 30p. Also included is Uncompressed DPX video recording in HD/2K in 10/12-bit up to 60p. Record Options available for purchase and/or rent via this website allow recording of ARRIRAW (ALEXA), Canon Cinema RAW (C500) Sony FS RAW (FS7/FS700 and POV RAW (IO Industries, Indiecam). FS RAW and Canon Cinema RAW also feature the ability to convert RAW signals into video and recording in Apple ProRes 422 (HQ). Additional recording formats will be added via firmware updates. Recording is to fast and reliable Odyssey SSDs, available in 256G, 512G and 1TB sizes. Two SSD slots allow for extended record times and high dataload recording.

Playback

All formats are available for immediate playback directly on the Odyssey7Q+. Full deck controls or tablet-style touchscreen scrubbing through clips makes playback quick and easy. On ProRes files, clip markers are available to quickly pinpoint important material. Image Analysis Tools are also available in Play Mode.

Multi-Stream Monitoring

View up to four HD video signals at once as a quad-split screen, or live-switch between inputs. Great for multi-camera shoots and internet streamed productions. Future Record Options will allow recording of four separate simultaneous Apple ProRes 422 (HQ) files, including a live-switch file and an edit decision list (EDL) in an XML file.

Future-proof

Use Odyssey7Q+ as a monitor today on any modern camera. Add an Odyssey SSD and the Odyssey7Q+ is ready to record. When shooting with a RAW output camera, Record Options can be purchased off the website at any time. Firmware updates continue to expand and refine the capabilities of the Odyssey7Q+

Affordable and Versatile

The same price as comparable OLED monitors in the market today, at US list $2295 the Odyssey7Q+ is the best on-camera monitor in the industry, PLUS it’s the most capable and versatile recorder available.

Lightweight, Efficient, Smart Design

Clever design and a magnesium alloy case keeps the Odyssey7Q+ to just over 1lb (560g). The Odyssey7Q+ consumes 8-19W depending on mode, can run on anything from 6.5-34v, and has no fans or venting to make noise or let in the elements.

Features

  • HDMI and SDI I/O - HD/2K/UHD/4K Recording over HDMI or SDI w/ conversion
  • LUT SUPPORT - ARRI Log-C, CANON C-Log, SONY S-Log, S-Log 2, S-Log 3
  • ASPECT RATIO GUIDES - Standard and Custom (user adjustable), may be used for framing guides, Horizontal/Vertical Framing Guides Available
  • FOCUS ASSIST - Video + Edges (Peaking), Edges Only, Enhanced Edges, user choice of color: Red, Green, or Blue
  • ZEBRAS - Adjustable zebra exposure indicators
  • FALSE COLOR - False Color with 5 programmable levels
  • WAVEFORM - Luma only, RGB Parade, Red only, Blue only, Green only, Full Size and Compact Size options
  • HISTOGRAM Luma only, RGB Parade, Red only, Blue only, Green only, Full Size and Compact Size Options
  • PIXEL ZOOM - 1:1 and 2:1 Image Magnification with frame drag
  • OUTPUT DOWNSCALING - Output 1080p HD via HDMI or SDI from 4K/UHD source (allows for additional on-set monitoring)
  • MULTI-STREAM DISPLAY - Display four simultaneous 1080 or 720 HD streams, HD-SDI and HDMI inputs supported in multiple formats
  • DIGITAL/ANALOG AUDIO - Multi-channel audio support via SDI, HDMI or 3.5mm analog ports
  • TIMECODE - Timecode: LTC I/O (BNC) or embedded timecode via HD-SDI & HDMI (limited to specific cameras
  • IN/OUT MARKERS - In/Out markers set during recording can be used during start/stop/playback and exported to NLE.
  • UPGRADEABLE - RAW Recording Options available for purchase or rental through our website. (Sony RAW, Canon RAW, ARRIRAW, POV Raw)
  • DUAL SSD SUPPORT - Dual drive architecture allows for long record time, high frame rate and high data rate recording.
  • RUGGED DESIGN - Magnesium alloy case for extreme durability in harsh conditions

Specifications


Display

7.7” OLED, 1280x800, RGB 8-bit panel, ~16 million colors, wide gamut, 3400:1 contrast ratio, 176° viewing, true blacks

SDI Video I/O

HD-SDI/1.5G / 3G support: Single/Dual/Quad Link inputs (HD/2K/Ultra-HD & 4K
supported), Dual HD-SDI 1.5G outputs, Full-size BNCs

HDMI Video Input

HDMI I/O Version 1.4b support, 8-bit, up to 1080p60 422,  up to 30 fps in Ultra-HD (3840 x 2160) and up to 24 fps in 4K (4096 x 2160)

HDMI Video Output

HDMI I/O Version 1.4a support, 8-bit, up to 1080p30 422

OLED Monitor

Vertical Auto-Flip (defeatable), Adjustable Color to match other monitor’s
calibration, Adjustable Saturation

Digital Audio I/O

2-channel SDI or HDMI embedded audio (48KHz, 24-bit)

Analog Audio I/O

3.5mm port for line level 2-channel unbalanced or 1-channel balanced input up to -10dB, 48KHz, 24-bit, 3.5mm stereo headphone output, adjustable

User Interface

Capacitive Touchscreen, three mechanical keys

Sound Level

Silent, no fan or vents, no RF emissions

DC Power Input

6.5 to 34VDC with built-in reverse polarity protection; locking power connector, built-in power switch

Power Draw

8 watts (monitor only), 9 to 18 watts (depending on selected record mode)

Weight and Size

560 grams / 1.2 lbs., 7.9”x 6.1”x 1.0” (200 x 155 x 25 mm),
-10 to +40°c (Operating), -20 to +70°c (storage)

Recording Media
(Dual SSD Slots)

Convergent Design Premium 2.5” SSDs with power-loss protection, in 256GB, 512GB and 1 TB sizes, 420Mb/sec write, 500Mb/sec read speed, compatible with USB 3.0 and Thunderbolt Adapters. One 256gb drive included as standard, Other SSDs and adapters sold separately.

Recording Formats
(Base Odyssey7Q+)

 Compressed formats:
 4K/UHD 10-bit YCC 422 up to 30 fps, in Apple ProRes 422 HQ
 2K/1080p 10-bit YCC 422 up to 60 fps, in Apple ProRes 422 HQ
 1080i 10-bit YCC 422 up to 60i, in Apple ProRes 422 HQ
 720p 10-bit YCC 422 up to 60 fps, in Apple ProRes 422 HQ
 Uncompressed formats:
 2K/1080p RGB 10/12-bit 444 up to 30fps, in DPX File Format
1080p RGB 10-bit 444 up to 60fps, in DPX File Format

** Available in the future via a free firmware update.
All specifications are subject to change without notice.

Record Times


Maximum Record Time In Minutes - Two 512GB SSDs (1TB)
Recording Format 24fps 25fps 30fps 50fps 60fps 100fps 120fps 200fps 240fps
4K/UHD Apple ProRes 422 (HQ) 154 148 123
2K Apple ProRes 422 (HQ) 617 592 494 296 247
1080p Apple ProRes 422 (HQ) 658 631 527 316 263
1080i Apple ProRes 422 (HQ)       658 527
720p Apple ProRes 422 (HQ)       710 593
2K Uncompressed DPX (RGB 444 12-bit) 64 61 51
2K Uncompressed DPX (RGB 444 10-bit) 71 69 57
1080p Uncompressed DPX (RGB 444 12-bit) 68 65 54
1080p Uncompressed DPX (RGB 444 10-bit) 76 73 61 37 30
ARRI ALEXA
ARRIRAW 16:9 90 87 72 43 36
CANON C500
Canon 4K/QHD RAW (4K Half RAW 100/120fps = 12 minutes) 56 54 45 27 23 30 25
SONY FS RAW
Sony 4K RAW 47 45 38 23 19
Sony 2K RAW (100fps = 40 minutes / 240fps = 20 minutes) 188 180 150 90 75 48 40 24 20
4K RAW to HD Apple ProRes 422 (HQ) "4K2HD" 660 636 528 316 264
4K RAW to 4K Apple ProRes 422 (HQ) “4K24K” 194 186 155
4K RAW burst = up to 440 frames
POV RAW
POV 2K 10-bit RAW 252 242 202 120 100
POV HD 10-bit RAW (120fps = 52 minutes) 268 256 214 128 106 62 52
POV HD 12-bit RAW 222 214 178 106 88

Formats


Video 4K/UHD/2K/HD (Included FREE with Odyssey7Q)

Compressed:

4K/UHD (4096x2160, 3840x2160): Apple ProRes 422 (HQ), 4:2:2 YCC 10-bit, frame rates: 23.98p, 24p, 25p, 29.97p

2K/HD (2048x1080, 1920x1080):  Apple ProRes 422 (HQ), 4:2:2 YCC 10-bit, frame rates: 23.98p, 24p, 25p, 29.97p, 50p, 59.94p, 60p, 50i, 60i

HD (1280x720):  Apple ProRes 422 (HQ), 4:2:2 YCC 10-bit, frame rates: 50p, 60p
See article: Recording Apple ProRes 422 HQ on the Odyssey7 & Odyssey7Q

Uncompressed:

2K/HD (2048x1080, 1920x1080):  Uncompressed video in DPX stacks, 12-bit/10-bit 4:4:4, frame rates: 23.98p, 24p, 25p, 29.97p, 30p.

2K/HD (2048x1080, 1920x1080): Uncompressed video in DPX stacks, 10-bit 4:2:2 (recorded as 4:4:4), frame rates: 23.98p, 24p, 25p, 29.97p, 30p, 50p, 59.94p, 60p

2K/1080p Support: 12-bit 23.98, 24, 25, 29.97 & 10-bit in DPX

3G-SDI: 2K/HD video over SDI up to 60p. 4K video over 4x SDI feeds, Accepted 1080p/psf frame rates: 23.98, 24, 25, 29.97, 30, 50, 59.97, 60 (adding More)
NOTE: 50, 59.97 & 60 are only available in DPX

HDMI: HD (1080) over HDMI up to 30p or 60i; HD (720) over HDMI up to 60p. Accepted 1080p/psf frame rates: 23.98, 24, 25, 29.97, 30, 50i, 60i

Future free firmware updates will include additional compressed video codecs with expanded frame rate, resolution selections, interlaced support, and pull down support.

ARRI  ALEXA ARRIRAW (Optional - Available for Purchase)

Supports all ARRIRAW formats and frame rates output by Alexa Classic cameras, recorded as .ari files.

ARRIRAW 16:9 frame rates: 23.98, 24, 25, 29.97, 30, 48*, 50*, 59.97*, 60*

ARRIRAW 4:3 frame rates: 23.98, 24, 25, 29.97, 30, 48* Future Firmware Update for 4:3

NOTE: ARRIRAW above 30fps requires two SSDs to simultaneously record. In a future firmware update only one SSD will be required for all frame rates.

In a future firmware update only one SSD will be required for all frame rates.

CANON C500 Cinema RAW (Optional - Available for Purchase)

Supports Canon C500 4K Cinema Raw, recorded as .rmf files.

4K RAW (4096x2160) frame rates: 23.98, 24, 25, 29.97, 50*, 59.94*

2K/1080p 12-bit support: 23.98, 24, 25, 29.97 & 10-bit

Future firmware updates will support 4K “Half RAW”, “slow & Fast” mode, and other C500 formats.

NOTE:  CANON RAW 50-60p requires two SSDs to simultaneously record.

SONY FS700 RAW (Optional - Available for Purchase)

Supports Sony FS700 4K & 2K RAW, high bit-depth HD derived from 4K, recorded as CinemaDNG .dng.

FS700 4K RAW frame rates: 23.98, 25, 29.97, 50, 59.94, 4K 440 frame burst mode: 100, 120

FS700 2K RAW frame rates: 23.98, 25, 29.97, 50, 59.94, 100, 120, 200*, 240*

NOTE: FS700 4K/2K RAW data is recorded as .DNG files.

FS700 4K RAW to Apple ProRes 422(HQ) / 10-bit / 23.98, 25, 29.97
Future firmware updates will support 4K compressed solutions, other recording options.

NOTE:   *2K RAW 200fps and 240fps require two SSDs to simultaneously record.
