Blackmagic Duplicator 4K

Code: NMA/VDUP2512G
$3,010.00
The Blackmagic Duplicator 4K is an SD card duplicator with built in realtime H.265 encoding, which is the new standard for delivering Ultra HD. The Duplicator 4K is the best way to deliver Ultra HD content that customers can actually view on their 4K televisions today.

ENQUIRE NOW

Got a question about this product?
Send us a message

Low Stock

Limited Stock - Call for availability

The Blackmagic Duplicator 4K makes it easy to deliver multiple copies of content to customers the moment an event is finished. You get an SD card duplicator with built in realtime H.265 encoding, which is the new standard for delivering Ultra HD. The Blackmagic Duplicator 4K is the best way to deliver Ultra HD content that customers can actually view on their 4K televisions today. The multi rate 12G-SDI connections let you record in all SD, HD and Ultra HD formats, up to 2160p60. The H.265 encoding gives you higher quality video in smaller files so you can use smaller and cheaper SD cards. You can even connect multiple duplicators together to make hundreds of recordings all at once!

Instantly Provide Content

Provide video the moment your live event is finished!

The best time to sell content is right after an event when people are still excited about it. Now you can capture the enthusiasm of impulse buyers and instantly provide a copy as they walk out the door.

Next Generation H.265

The new standard for Ultra HD delivery

The Blackmagic Duplicator 4K encodes using H.265, the new standard for Ultra HD delivery. You get a built in realtime H.265 hardware encoder that gives you incredible looking Ultra HD video, even at high frame rates up to 2160p60. The H.265 video looks better than H.264, the files are small, and the data rates are low so you can play your content back from standard SD card media! You can even play back Ultra HD 2160p60, which is 4 times the size of regular HD and twice the frame rate. Now you can deliver dramatically better looking video to your customers using small and affordable SD cards.

Deliver Ultra HD

Content that customers can view on their 4K TVs today

With 4x the resolution of regular HD, Ultra HD is the future of television! With estimates that over 70% of televisions sold worldwide are Ultra HD, that means Ultra HD is here now. The promise of Ultra HD is stunning, crystal clear images that have much better color and far more detail than regular HD. Until now, there’s been no way to deliver high quality 4K to consumer televisions. The Blackmagic Duplicator 4K lets you deliver Ultra HD content directly to your customers that they can play on their Ultra HD televisions today.

Compact Design

Everything you need to encode, duplicate and sell content at live events

The Blackmagic Duplicator 4K features a realtime H.265 encoder and 25 SD card recorders that are miniaturized into a single rack unit design. The machined metal design is durable, lightweight and small enough to take anywhere. That means you can duplicate content right where you’re recording and selling it. You get an attractive LCD display for status, professional broadcast connections such as 12G-SDI with loop through and RS-422 deck control so you can connect multiple units together and record more cards at the same time.

Work Solo

Automatically trigger recording from your camera

Working with multiple cameras and a live production switcher is very fast and creative, however many events only require a single camera and operator. If you’re working alone, you can still produce multiple copies and sell content faster than ever before. Simply plug the SDI output from your camera into the duplicator, start shooting and the Blackmagic Duplicator 4K will automatically start encoding and making copies. The Blackmagic Duplicator 4K recognizes the SDI start/stop commands from the camera so it automatically starts and stops recording whenever you start and stop the camera.

Rapid Card Formatting

Quickly format all cards without using a computer

With the Blackmagic Duplicator 4K you can easily load and format all 25 cards from the front panel at the same time. That means you don’t have to format them one at a time on your computer. At the end of the event you can take cards out as you sell them and because the cards are re-usable, you can simply reformat and record over the unsold cards at your next event.

Create Unlimited Copies

Record hundreds of copies in real time

For larger events, you can connect multiple Blackmagic Duplicator 4Ks together and record an unlimited number of copies, all at the same time. Simply loop the RS-422 deck control and SDI video to multiple duplicators, then start recording on the first one. When you push a button on the front panel of the first unit, it sends the command out via the RS-422 remote and into all of the connected units so they all start recording simultaneously. You can set up a road case with enough duplicators to handle massive events and because the cards are re-usable, you never have to worry about wasting media because you can simply record over them again later.

Single File Recording

Easily merge multiple shots into a single file

The Blackmagic Duplicator 4K includes revolutionary new append record button that lets you seamlessly combine recordings from different parts of an event into a single file. For example, if you are recording events that have natural breaks, like weddings with a ceremony and reception in different locations, the Blackmagic Duplicator 4K can automatically append the recordings all into a single file. This makes it easier for guests to watch because they only have to play back a single movie.

Small, Low Cost SD Cards

Readily available, super thin, inexpensive and high speed

There’s no better way to deliver content than with super small, high speed SD cards. SD cards are readily available, affordable and are compatible with computers and TVs. Plus, when it comes to packaging content quickly, they’re easy to label and put into attractive, presentable wallets that look great at point of sale. The Blackmagic Duplicator 4K records using H.265, so you can easily fit a one hour Ultra HD program onto a very cheap 8GB SD card. Best of all, the cards can be re-used, so the extras can be recorded over and used again at your next event.

Ultra HD Distribution

No proprietary players needed

The Blackmagic Duplicator 4K records video in an open file format using H.265, which is the standard for Ultra HD delivery. Combined with SD card media, you get a solution that’s compatible with virtually everything. SD cards can contain SD, HD or Ultra HD video and work with both Mac and Windows computers. You can even use a USB adapter to plug them directly into your Ultra HD television set. Unlike proprietary disc based formats, like Blu-Ray, you don’t have to buy a slow and expensive player. The Blackmagic Duplicator 4K is the easiest, most compatible and cost effective way to distribute Ultra HD content today.

Specifications

SD Card Support Class 10 minimum, will support UHS-I and UHS-II cards.
Connections
SDI Video Input 1 x 10 bit SD/HD/UHD auto switching
SDI Video Output Automatically matches the SD/HD/UHD 12G-SDI input
SDI Audio Input 16 channels embedded
SDI Audio Output 16 channels embedded
Optical Input 1 x 10 bit SD/HD/UHD auto switching
Optical Output 1 x 10 bit SD/HD/UHD auto switching
SD Card Interface 25 x SD Card Slots
Device Control Sony™ compatible RS422 deck control port x 2. 1 x in plus 1 x out
Computer Interface 1 x USB 2.0 Mini-port for software updates and Blackmagic Duplicator software control
Ethernet Ethernet supports 10/100/1000 BaseT
Standards
SD Format Support 525i59.94 NTSC, 625i50 PAL
HD Format Support 720p50, 59.94
1080p23.98, 24, 25, 29.97, 30, 59.94, 60 1080PsF23.98, 24
1080i 60
Ultra HD Format Support 2160p23.98, 24, 25, 29.97, 30, 50, 59.94, 60
SDI Compliance SMPTE 259M, 292M, 296M, 425M
Audio Sampling Television standard sample rate of 48 kHz and 24 bit uncompressed
Video Sampling 4:2:2
Codecs
Supports H.265@ 4:2:0 with AAC audio
Software
Software Included Blackmagic Duplicator
Internal Software Upgrade Firmware built into software driver. Loaded at system start, or via updater software
Operating Systems
Required Mac OS X 10.9 Mavericks
Mac OS X 10.10 Yosemite,
Mac OS X 10.11 El Capitan or later
Windows 8.1 64-bit
Windows 10 64-bit
General
Power Supply IEC Connector with fuse 110v-240v
Size 482mm x 198.5mm x 44mm
Weight (2kg)
Operating Temperature 5 to 50°C Environment
Storage Temperature -20°to 50°C (-4° to 113°F)
Relative Humidity 0% to 90% non-condensing
Power Requirements 110-240V
What's Included Blackmagic Duplicator 4K
Software SD Card
Warranty 12 Month Limited Manufacturer's Warranty
