Computer Interface
|
PCI Express 8-lane, compatible with 8 and 16 lane PCIe slots
|
|
Input / Output
|
8 x Bi-directional SD/HD/3G-SDI, 12-bit (DIN 1.0/2.3 connectors)
1 x Reference Input (DIN 1.0/2.3 connector)
|
|
SDI Audio Input
|
16 channels per input, embedded in SD and HD
|
|
SDI Audio Output
|
16 channels per output, embedded in SD and HD
|
|
Sync Input
|
Blackburst in SD, 720p50, 720p59.94, 1080i50, and 1080i59.94 formats or Tri-Sync in any HD format
|
|
Codecs Supported
|
AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, HEVC, XDCAM EX, XDCAM HD, XDCAM HD422, Apple ProRes 4444, Apple ProRes 422 (HQ), Apple ProRes 422, Apple ProRes (LT), Apple ProRes 422 Proxy, Uncompressed 8-bit 4:2:2, Uncompressed 10-bit 4:2:2, Uncompressed 10-bit 4:4:4
|
|
Resolutions and Frame Rates
|
625/25 PAL
525/29.97 NTSC
720p 50/59.94/60
1080i 50/59.94/60
1080PsF 23.98/24/25/29.97/30
1080p 23.98/24/25/29.97/30/50/59.94/60
|
|
SDI Compliance
|
SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 425M A/B
|
|
SDI Metadata Support
|
VITC read for 3:2 pulldown removal
VANC capture and playback using up to 3 lines of video in file
HD RP188 and closed captioning
|
|
Audio Sampling
|
48 kHz, 24-bit
|
|
Video Sampling
|
4:2:2, 4:4:4
|
|
Color Precision
|
8/10-bit YUV 4:2:2
8/10/12-bit RGB 4:4:4
|
|
Color Space
|
Rec. 601, Rec. 709
|
|
Compatible Operating Systems
|
Mac OS X 10.10, 10.11, and later
Windows 8 and Windows 10 64-bit
Linux
|
|
Operating Temperature
|
32 to 104°F (5 to 40°C)
|
|
Storage Temperature
|
-4 to 113°F (-20 to 45°C)
|
|
Relative Humidity
|
0 to 90% non-condensing
|
|
Length
|
6.3" (16 cm)
|
|
Weight
|
4.59 oz (130.12 g)
|
